XStream™OEMRFModule–ProductManualv5.x00[2006.02.24]
©2006MaxStream,Inc.ConfidentialandProprietary 49
FCC-Approved Antennas
TableA‐01. Antennasapp tream(900MHz)OEMRFModules.rovedforusewith9XS
Manufacturer Part Number Type Gain Application Min. Separation Distance
* * Yagi 6.2 dBi Fixed/Mobile ** 20 cm
* * Yagi 7.2 dBi Fixed/Mobile ** 20 cm
MaxStream A09-Y8 Yagi 8.2 dBi Fixed/Mobile ** 20 cm
* * Yagi 9.2 dBi Fixed/Mobile ** 20 cm
* * Yagi 10.2 dBi Fixed/Mobile ** 20 cm
MaxStream A09-Y11 11.2 dBi Fixed/Mobile ** 20 cm (FCC pending) Yagi
MaxStream A09-F2 Omni Direct. 2.2 dBi Fixed ** 20 cm
MaxStream A09-F5 Omni Direct. 5.2 dBi Fixed ** 20 cm
MaxStream A09-F8 Omni Direct. 8.2 dBi Fixed ** 20 cm
* 20 cm * Omni Direct. 9.2 dBi Fixed **
* * Omni Direct. 7.2 dBi Fixed ** 20 cm
MaxStream A09-M7 Omni Direct. 7.2 dBi Fixed ** 20 cm
MaxStream 2.1 dBi Fixed/Mobile ** 20 cm A09-H 1/2 wave antenna
MaxStream A09-HBMM-P5I 1/2 wave antenna 2.1 dBi Fixed/Mobile ** 1 cm
MaxStream A09-QBMM-P5I 1/4 wave antenna 1.9 dBi Fixed/Mobile ** 1 cm
* *
1/4 wave integrated
wire antenna
1.9 dBi Fixed/Mobile ** 1 cm
TableA‐02. Antennasapprovedforusewith24XStream(2.4GHz)OEMRFModules.
Manufacturer Part Number Type Gain Application Min. Separation Distance
* Yagi 6 dBi Fixed ** 2 m *
* * Yagi 8.8 dBi Fixed ** 2 m
* * Yagi 9 dBi Fixed ** 2 m
* * Yagi 10 dBi Fixed ** 2 m
* * Yagi 11 dBi Fixed ** 2 m
* * Yagi 12 dBi Fixed ** 2 m
* * Yagi 12.5 dBi Fixed ** 2 m
* * Yagi 13.5 dBi Fixed ** 2 m
* Yagi 15 dBi Fixed ** 2 m *
* * Omni Direct 2.1 dBi Fixed/Mobile ** 20 cm
* * Omni Direct 3 dBi Fixed/Mobile ** 20 cm
* * Omni Direct 5 dBi Fixed/Mobile ** 20 cm
* * Omni Direct 7.2 dBi Fixed ** 2 m
* * Omni Direct 8 dBi Fixed ** 2 m
* * Omni Direct 9.5 dBi Fixed ** 2 m
* * Omni Direct 10 dBi Fixed ** 2 m
* * Omni Direct 12 dBi Fixed ** 2 m
* Fixed ** 2 m * Omni Direct 15 dBi
MaxStream A24-P8 Panel 8.5 dBi Fixed ** 2 m
MaxStream A24-P13 Panel 13 dBi Fixed ** 2 m
* * Panel 14 dBi Fixed ** 2 m
* * Panel 15 dBi Fixed ** 2 m
* * Panel 16 dBi Fixed ** 2 m
MaxStream A 2 m 24-P19 Panel 19 dBi Fixed **
MaxStream A24-HABMM-P6I Dipole 2.1 dBi Fixed/Mobile ** 20 cm
MaxStream A24-HBMM-P6I Dipole 2.1 dBi Fixed/Mobile ** 20 cm
MaxStream A24-HABSM Dipole 2.1 dBi Fixed/Mobile ** 20 cm
MaxStream A24-QABMM-P6I Monopole 1.9 dBi Fixed/Mobile ** 20 cm
* A24-Q1 Monopole 1.9 dBi Fixed/Mobile ** 20 cm
* Fixed/Mobile ** 20cm * Monopole 1.9 dBi

*FCC‐approvedantennasnotinventoriedbyMaxStream–ContactMaxStream(866)765‐9885forinformation.
**CanbeapprovedforportableapplicationsifintegratorgainsapprovalthroughSARtesting

