From table 4.8.7.1 below, we know that the register address of the present voltage value is 0x0B00,
Query: 0x01 0x03 0x0B 0x00 0x00 0x02 0xC6 0x2F
The Corresponding Logical Response: 0x01 0x03 0x04 0x41 0x20 0x00 0x2A 0x6E 0x1A, within which,
0x41 0x20 0x00 0x2A is the read-back voltage valueand the corresponding floating point value is 10V.
4. Preset Multiple Registers (0x10)
Preset Multiple Registes Example Query
Field Name Byte length Example Value
Slave Address 1 1~200
Function Code 1 0x10
Starting Address 2 0~0xFFFF
No. of Registers 2 n=1~32
Byte count 1 2*n
Preset Data 2*n
CRC Error Check 2
Preset Multiple Registers Example for a Logical Response
Field Name Byte length Example Value
Slave Address 1 1~200
Function Code 1 0x10
Starting Address 2 0~0xFFFF
No. of Registers 2 N
CRC Error Check 2
Preset Multiple Registers Example in an Illogical Response
Field Name Byte length Example Value
Slave Address 1 1~200
Function Code 1 0x90
Abnormal Code 1 01~04
CRC Error Check 2
Example：
The following example sets the load’s constant current IFIX as 2.3A at the slave device address of 0x01.
From table 4.8.7.1 below, we know that the IFIX register address is 0x0A01and the floating point takes up
a two-word length.
Query: 0x01 0x10 0x0A 0x01 0x00 0x02 0x04 0x40 0x13 0x33 0x33 0xFC 0x23
The Corresponding Logical Response: 0x01 0x10 0x0A 0x01 0x00 0x02 0x13 0xD0
4.8.7 Coil With The Register Address Allocation
Table 1: Coil-bit definition:
Name Address
Bit Property
Description
PC1 0x0500 1 W/R When the remote control status bit is set to 1, the
front key panel is disabled
PC2 0x0501 1 W/R When the local prohibition bit is set to 1, the
"Shift +7" keys on the front panel are disabled
TRIG 0x0502 1 W/R Trigger tagged: triggered once by software
command
