3
Model M9712B30
Power 300W
Current 0-30A
Input Rating
Voltage 0-500V
Range 0-3A 0-30A
Resolution 0.1mA 1mA
CC Mode
Accuracy 0.05%+0.05%FS 0.05%+0.08%FS
Range 0.1-19.999V 0.1-500V
Resolution 1mV 10mV
CV Mode
Accuracy 0.03%+0.02%FS 0.03%+0.05%FS
Range 0.3Ω-10K 0.3Ω-5K
Resolution 16 bit 16 bit
CR Mode
(Voltage and current input
value ≥10% full measument)
Accuracy 0.1%+0.1%FS 0.1%+0.1%FS
Range 0-300W 0-300W
Resolution 1mW 10mW
CW Mode
(Voltage and current input
value ≥10% full measument)
Accuracy 0.1%+0.1%FS 0.1%+0.1%FS
Voltage 0-19.999V 0-500V
Resolution 1mV 10mV
V Measurement
Accuracy 0.015%+0.03%FS 0.015%+0.05FS
Current 0-3A 0-30A
Resolution 0.01mA 0.1mA
I Measurement
Accuracy 0.05%+0.08%FS 0.08%+0.08%FS
Watt 100W 300W
Resolution 1mW 10mW
W Measurement
(Voltage and current input
value ≥10% full measument)
Accuracy 0.1%+0.1%FS 0.1%+0.1%FS
Battery Measurement Battery Input: 0.5-
120V; Max. Measurement: Capacity=999/H; Resolution=0.1mA;
Time Range=1S-16HS
Dynamic Measurement Transition List: 0-25kHZ; 2.5A/uS; T1&T2:60uS-999S; Accuracy: + 15%
offset+10% FS
CC soft-startup Time 1 mS; 2 mS; 5mS; 10mS; 20 mS; 50 mS; 100 mS; 200 mS Accuracy: + 15%
offset+10% FS
Current(CC) 3.3A≒ 33A≒
Voltage(CV) 0V
Short Circuit
Resistance(CR) 280mΩ≒
Operating 0～40℃
Temperature
Nonoperating –10℃～70℃
Dimension
W*H*D(mm) 108*214*365
Weight
Kg 3.5
