42 PROGRAMMING MANUAL 516532 B PUBLICATION DATE 1 JUN 2007.DOC
• The purpose of the Toolbox Menu is to give support at
technical intervention.
• Input states let you verify the electrical signals into the wash
computer.
• Input 1 : the State that corresponds with Input 1.
Input 2 : the State that corresponds with Input 2.
…
Input 16 : the State that corresponds with Input 16.
• The exact function of the inputs can be found on the
electrical drawing of the Graphic Control Wash Machine.
• If the Input state is Off, the Input signal is low.
• If the Input state is On, the Input signal is high.
• For washing machines with Frequency Inverter Controlled
motor only.
• By this function it‘s possible to switch on the power for the
inverter if a technical intervention is needed.
• By selecting YES, the power of the inverter is switched on.
ATTENTION !!!
SPECIAL CARE HAS BEEN TAKEN AT THE INITIALIZATION OF THE PARAMETERS OF THE
MITSUBISHI FREQUENCY INVERTER.
THE MANUFACTURER IS NOT RESPONSIBLE FOR THE WRONG BEHAVIOR OF THE
WASHING MACHINE IF THE OWNER HAS INSTALLED NEW PARAMETER SETTINGS IN THE
INVERTER THAT DO NOT CORRESPOND WITH THE ORIGINAL SETTINGS AT THE FACTORY.
• XX is the Pulley Ratio.
• You can check if the motor pulley and the drum pulley have
the correct size by calculating the pulley ratio.
• This value should be about the same as the displayed value.
• This value can not be changed.
• To inform the operator that preventive maintenance must be
fulfilled when the machine has reached the number of cycles
that corresponds with the „Service Interval“. A service Due
symbol will be shown until the Cycle Counter at the Service
menu has been reset.
• Also the Statistics for Diagnostic messages will be Reset by
resetting the Cycle counter.
Toolbox…
Service Menu
View Input States…
Service Tool Box
!
Inverter Power Off
Service Tool Box
Pulley Ratio 4.38
Service Tool Box
1 In
ut 1 Off
2 In
ut 2 Off
3 In
ut 3 On
4 In
ut 4 On
Service Statistics
Reset Service Counts No
Service Tool Box
To Next Page
