BASIC DIAGNOSTIC WASH PROGRAM
54
BASIC Diagnostic Wash program
Error messages:
If the computer detects some problem during the Diagnostic Help Program, a diagnostic error message is generated.
Also check the Error Log List in the Service Menu.
Check the error handling and explanation of the error messages.
Step 1
Step 2
Step 3
Sequence Supply Inlet Temp Level Wash action Time R.P.M.
Wash
B 3-4-5
104°F (40
°
C)
NL A=12 sec R=3 sec 6 min W
Drain
– – – – – 30 sec D
Rinse 1
– 2-5-6 – NH A=12 sec R=3 sec 1.5 min W
Spin
– – – – – 1 min L
Final Rinse
C 1(+6) – NL A=12 sec R=3 sec 2 min W
Spin
– – – – – 4.5 min H
Slowdown
– – – – – 1 min –
Tumble
– – – – A=12 sec R=3 sec 30 sec W
