3-44
1. Remove the front plate. (See page 3-41)
2. Remove three T-20 screws that secure the
door lock behind door support front plate.
(See page 3-40)
3. Remove fifteen 10mm nuts that secure door
support front plate to the tub front cover.
4. Use a pry bar behind the door support front
plate, around the tub opening, to remove it
from the tub front cover.
NOTE: There are hinge plates riveted on
the inside.
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before
operating.
DOOR SUPPORT FRONT PLATE
10mm Nuts
Hinge
Plates
To Next Page
