26
Soft-Mount and Rigid-Mount
Model (lb/kg) 20/9 25/11 30/14 40/18 55/24 65/28
Water Connection
Water Inlet Connection BSP 3/4"
Water Pressure Range 14.5–116 PSI/0.1–0.8 MPa/1–8 bar
Recommended Water Pressure 43–73 PSI/0.3–0.5 MPa/3–5 bar
Maximum Water Temperature 194°F/90°C
Drain Connection
Drain Type Gravity Feed
Drain Valve Diameter 3" (76 mm)
Flow Rate 55.5 gal/min (210 L/min)
Dispensing
Liquid Soap Signals 8 (See electrical schematic)
Soap Dispenser 4 Compartments (Prewash, Powder Wash, Liquid Wash, Fabric Softener/Last Rinse)
Working Conditions
Ambient Temperature 41 to 95°F/5 to 35°C
Relative Humidity 30% to 90% without condensation
Height Above Sea Level Up to 3280' (1000 m)
Storage Temperature 34 to 131°F/1 to 55°C
