Wipers
www.MazdaUSA.com
WINDSHIELD WIPER/WASHER CONTROL LEVER
AUTO: The rain sensor senses the amount of rainfall and turns the wipers
on or off. Rotate inner ring away from you (clockwise) for more sensitivity
(requires less rain to turn wipers on) and toward you (counterclockwise)
for less sensitivity (requires more rain to turn wipers on).
CAUTION: If the ignition is ON, turn the AUTO wipers OFF when going
through a car wash, or while cleaning or touching the windshield.
NOTE: Vehicles not equipped with
AUTO wipers will have INT wipers. Set
the lever to INT and choose an interval
timing by rotating the ring between fast
and slow.
Pull lever
to dispense
windshield
washer uid
Less sensitive
More sensitive
1
2
3
HI
LO
AUTO
OFF
MIST
Rear Window
Wiper/Washer
(Hatchback)
INT: Intermittent
ON: Normal speed
: Washer/wiper
(hold as desired)
