REASSEMBLY
VEHICLE REASSEMBLY
Follow along the dual amplier audio harness and zip tie the harness to the machine to assure it doesn’t
come loose during rides. Do not zip tie the harness to any heat or moisture sources. Also ensure the point
at which the harness passes through the lewall grommet is sufciently sealed with electrical tape, silicone-
based caulking or equivalent. Once your harness is secure and the rewall grommed is sealed, you can
begin reassembling all the panels.
Here is an important checklist so you do not forget anything:
2013-2018 RZR Models
● ENSURE FIREWALL GROMMET IS WELL SEALED WHERE HARNESS PASSES THROUGH
● REINSTALL CENTER CONSOLE
● REINSTALL SEATS TIGHTEN NEGATIVE BATTERY TERMINAL FULLY
● OIL COVER ON ENGINE COMPARTMENT BEHIND THE SEATS
● REINSTALL CENTER CONSOLE
● REINSTALL SEATS
● TIGHTEN NUTS ON STEERING WHEEL COLUMN (2013-2018 Models) - 40 FT/LB of TORQUE*
● FRONT OF DASH - CHECK ALIGNMENT WHERE THE DASH MEETS THE SUBWOOFER
● ZIP TIE STAGE 5 WIRING HARNESS WHILE AVOIDING HEAT SOURCES OR MOVING PARTS
● REASSEMBLE TOP OF DASH
● REPLACE HOOD
*NOTE – It is critical to the safe operation of your vehicle that the nuts holding the steering column be re-
tightened to 40 foot pounds of torque.
2018.5 Turbo S and 2019+ RZR Models
● ENSURE FIREWALL GROMMET IS WELL SEALED WHERE HARNESS PASSES THROUGH
● TIGHTEN NEGATIVE BATTERY TERMINAL FULLY
● REINSTALL ECU BRACKET - TIGHTEN TWO 10MM BOLTS
● FINAL FIT OF AMPLIFIER BRACKET - TIGHTEN REMAINING TWO 10MM BOLTS FOR ECU BRACKET
● OIL COVER ON ENGINE COMPARTMENT BEHIND THE SEATS
● REINSTALL CENTER CONSOLE
● REINSTALL SEATS
● NUTS ON STEERING WHEEL COLUMN (2013-2018 Models) - 40 FT/LB of TORQUE*
● FRONT OF DASH - CHECK ALIGNMENT WHERE THE DASH MEETS THE SUBWOOFER
● ZIP TIE STAGE 5 WIRING HARNESS WHILE AVOIDING HEAT SOURCES OR MOVING PARTS
● REASSEMBLE TOP OF DASH
● REPLACE HOOD
