MBM 508A - Adjustment of Paper Ejection Roller Position

28
5-6-3 : Adjustment of paper ejection roller position
[1] Select the paper ejection roller position using “↑” and
“↓” keys (5 levels)
.
Hint !
For standard folding of standard-size paper, the paper ejection roller will be automatically set to the
optimal position for the fold position, fold type and speed.
In the case of non-standard-size paper or non-standard fold, adjust the position of the paper ejection
roller.
[ Rough indication ]
▪ For larger finished dimension ….... Paper ejection roller => To the direction to 5
▪ For smaller finished dimension ….. Paper ejection roller => To the direction to 1
▪ For higher processing speed ….….. Paper ejection roller => To the direction to 5
▪ For lower processing speed …. ….. Paper ejection roller => To the direction to 1
