43
6-6 : Removal and installation of paper separator, paper feed rubber roller, brake rubber
When replacing the paper feed rubber roller and paper separator, remove them in the following manner.
Hold both ends of the paper separator (covered with
resin) and pull it out.
When fitting it, proceed in the reverse order to the
removal process.
To purchase above parts, contact your dealer.
Press paper feed roller shaft to the
right and spring loaded shaft will be
removed without tools.
