MBM GFTA477L - Instructions for Use; Location of main components; Knobs, keys and indicator light modes and functions

7
THE PRESENT MANUAL IS PROPERTY OF THE MANUFACTURER. ANY REPRODUCTION, EVEN PARTIAL, IS PROHIBITED.
- 7 -
INSTRUCTIONS FOR USE
5.
7- 7 -
3.
3
0
0
2
7
0
2
5
0
2
3
0
2
1
0
1
9
0
.
1
7
0
Knobs, keys and indicator light modes and functions
The layout of the keys in the gures is purely indicative and can be subject to variations.
Thermostat knob (GAS). It performs three different functions:
1. Igniting the pilot light and burner.
2. Temperature regulation.
3. Turning the appliance off.
Piezoelectric button (GAS). It performs one function:
1. When pressed, it produces the spark to ignite pilot light.
Location of main components
The layout of the gures is purely indicative and can undergo variations.
1. Piezoelectric button (see Knobs, keys and indicator light
modes and functions).
2. Thermostat knob (see Knobs, keys and indicator light modes
and functions).
3. Hotplate.
4. Cooking oil/grease collection container.
1
2
1
2
4
3 3
