- 12 -
BONNET GRANDE CUISINE
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
16 PREVENTATIVE MAINTENANCE
The appliance must be isolated electrically during cleaning or maintenance and when replacing parts.
Every year
(Or every
3000 h)
Cleaning the external surfaces
Use the correct dose of cleaning product; Do not use
abrasive products.
Cleaning the cavity seal (all models) and bottom door seal
(20 levels)
Use the correct dose of cleaning product; Rinse
thoroughly; Do not use abrasive products.
Visual inspection of cavity seal (all models) and bottom
door seal (20 levels)
In case of damage, alert the after-sales service
Cleaning and descaling of internal surfaces
Respect cleaning product dosage; Rinse thoroughly;
Alert the after-sales service if any rust points appear.
Checking the amount of cleaning agent in the container
Replace the container as often as necessary
Checking the condition of the hose and of the base valve in
the cleaning agent container
Check when replacing the container / Clean the base
valve
Cleaning the electronic compartment ventilation openings
Visual check of the presence of inner door stops
Visual check of the condition of the lighting strip label
Clean if necessary with a non-aggressive and non-
abrasive degreaser. Rinse thoroughly. In case of
damage, alert the after-sales service
Visual inspection of the core probe (tip, cable, passage
through the bulkhead)
In case of damage, alert the after-sales service
Periodic maintenance by the after-sales service
17 ERROR MESSAGES
i31 : Electronics overheating: Temperature
reduced to 180°C
Cooking continues automatically
at a temperature below 180°C
Clean the lower and rear air intakes. If the problem
persists, call a service technician.
i33 : Core probe non function or not plugged in
To continue cooking connect a probe or switch to timer mode.
Reduced functionality or Pause
the cleaning
Check the valve and water pressure.
If the message appears during a cleaning cycle it is
possible to stop the cycle if the cleaning chemicals have
not yet been injected, by pressing stop. Check that the
water has not been switched off to recommence the cycle
automatically. If this is not the case the cycle is blocked.
To force an end to the cycle :
- press on « Tools/Cleaning »
- enter the PIN code « RSTC » to exit
- manually undertake a thorough rinse of the cooking
cavity to eliminate all chemical residues before
cooking
- call a service technician
Switch off and call a service technician.
E46 : Electronic communication fault
Possible to launch safe mode: convection mode at 175°C
(see guidance and info about the control screen).
E53 : Ventilation non function
Switch off and call a service technician.
E61 : Ambient probe short circuit
Switch off and call a service technician.
E62 : Ambient probe non function
Switch off and call a service technician.
Switch off and call a service technician.
E72 : Electronics at over + 75°C
Switch off and call a service technician.
E73 : Detergent pump faulty or on permanently
Drain the hydraulic circuit.
Reduced functionality
Switch off and call a service technician.
BONNET GRANDE CUISINE
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
18 RECOMMENDED AND FRONT LINE SPARE PARTS
1 way 1 x 10 L/min solenoid valve
Drive shaft gasket + wear ring
Complete mounted sensor sub-assembly of oven generator
2 way 2 x 10 L/min solenoid valve
3 way 3 x 10 L/min solenoid valve
3 way 2 x 10 L/min + 1 x 5 L/min solenoid valve
Sub assembly - Gas valve without safety enclosure
After sales kit 9kW element 340 dia + seal
After sales kit 15kW element 500 dia + seal
After sales kit 9kW element 430 dia + seal
After sales kit 7.5kW immersion heater 380 long
After sales kit 6kW immersion heater 380 long
After sales kit 24kW immersion heater 570 long
After sales kit 17.7kW immersion heater 570 long
After sales kit 8kW immersion heater 380 long
4 way solenoid valve, 2 x 10 L/min + 2 x 5 L/min
Three-pole 25A 230V 50/60 Hz contactor
Three-pole 32A 230V 50/60 Hz contactor
Three-pole 40A 230V 50/60 Hz contactor
Three-pole 50A 230V 50/60 Hz contactor
Three-pole 80A 230V 50/60 Hz contactor
Ultra fast fuse 0.2A 250V 5 x 20
PT100 sensor, diameter 4, 350 in length
2 points PT 100 regulating sensor
1 point regulation probe, PT 100
LN2 fixed centrifugal fan 7000rpm
Reducing gear with centre return spring, 85 degrees
Switching regulator 15V 15W RS 15-15
FastPAD 2 max power assembly
FastPAD 2 Mini relay connection
FastPAD 2 Max UL relay connection
Motorised valve 3/4 230V 50/60 Hz female
Inlet/outlet 1 way solenoid valve, 10 L/min
10.2 x 15 diameter 2 mm thick metal-asbestos plastic gasket
Heating element + immersion heater gasket
