Overview
2 - 3
Gas Powered Units
Read the operating and maintenance instructions for the engine
before operating.
The engine is a single cylinder, overhead valve, air cooled
design. It uses a vacuum operated fuel pump.
The fuel shutoff valve is located by the carburetor.
TX01987-1-10-02
PH01965-11-15-00
Diesel Powered Units
Read the operating and maintenance instructions for the engine
before operating.
The engine is a twin cylinder water cooled design. It uses an
electric fuel pump located near the fuel tank.
TX01855-11-15-00
PH01960-11-15-00
Tach and Hour Meter for Gas Unit
When the unit is running, the engine speed is displayed. When
the unit is not running, total hours of engine operation are
displayed.
On diesel powered units an hour meter is provided in the same
location.
TX01892-11-15-00
PH01988-11-15-00
PH02243-1-10-02
