McElroy TracStar 412 - Special Operations - Facer Removal (Model 28); Removing Facer from TracStar No.28 Machine

Remove Facer From TracStar No.28 Machine
Loosen facer locking bolt.
Lift facer out of the carriage and set on cardboard or wood
blocks off of ground.
Remove rear guide rod bracket.
Attach rear guide rod bracket in the position shown.
TX01874-11-8-00
Special Operations - In Ditch
PH01930-11-15-00
PH01981-11-15-00PH01980-11-15-00
4 - 4
