Clamp Carriage Assembly to Pipe
Position carriage assembly on side of the pipe. Lift pipe and slide
carriage assembly under pipe.
Rotate carriage assembly around to a normal upright position.
Attach the top jaws and loosely clamp around pipe.
TX00879-2-19-96
CD00193b-2-19-96CD00194b-2-19-96CD00195a-2-19-96
Special Operations - In Ditch
4 - 7
