Dimensions
Dimensions
The following dimensions can assist in determining
the best location for your C47. There is additional
information on the next page pertaining to installing
the C47 into cabinets.
17-1/2"
44.4cm
13 -1/4"
33.7cm
17-1/8"
43.5cm
3/16"
0.48cm
13/16"
2.1cm
10-9/16"
26.8cm
14-1/2"
36.8cm
2"
5.1cm
1-15/16"
4.9cm
Front View of the C47
Rear View of the C47
Side View of the C47
6"
15.2cm
5-3/8"
13.7cm
4-5/8"
11.8cm
4-13/16"
12.22cm
16-1/2"
41.9cm
