16
Remote Control Buons
Activates Trim Mode
Selects the desired INPUT
Select the desired active TRIM function; also
manually tune up the dial with contemporary
McIntosh Tuners
Adjusts the active TRIM Function
Adjusts the active TRIM Function
Directional Push-buttons - Up,
Down, Left and Right
LED illuminates during the time a
remote command is sent to the C8
Increases the volume levelDecreases the volume level
Mutes and unmutes the audio
Powers the C8 ON or OFF
Select the desired active TRIM function;
also manually tune down the dial with
contemporary McIntosh Tuners
Selects Previous Track during
CD Playback
Selects Next Track during CD Playback
Stop CD Playback
Pause CD Playback
Starts CD Playback

Other manuals for McIntosh C8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the McIntosh C8 and is the answer not in the manual?

McIntosh C8 Specifications

General IconGeneral
TypeVacuum Tube Preamplifier
Output Impedance200 ohms Unbalanced
Input Impedance Unbalanced50K ohms
Voltage Gain High Level15dB
Signal to Noise Ratio Phono75dB
Tube Complement4 x 12AX7A
Frequency Response20Hz to 20kHz +0, -0.5dB
Total Harmonic Distortion0.08%
Input Impedance50k ohms
Signal to Noise Ratio100dB
High Level Inputs4 Unbalanced
Phono Inputs2
Rated Output Voltage2.5V
Headphone OutputYes
Outputs2 Unbalanced
