McIntosh MP1100 User Manual

15
22. To save the new name, press and hold in the
INPUT Control until “SAVE, SUCCESSFUL”
appears on the Front Panel Information Display.
Refer to figure 19.
23. Exit the SETUP Mode by pressing the INPUT
Control.
Note: For convenience, an “Input name” chart below has
been provided to keep track of changes.
on the Display. If necessary rotate the INPUT
Control to select the PHONO 1 Input. To select a
different Profile to save the new Phono Load and
Mode Settings, rotate the LOAD Control to select
(U2, U3, U4 or U5). Refer to figure 21.
4. To save the new Profile, press and hold in the
INPUT Control until “SAVE, SUCCESSFUL”
appears on the Front Panel Information Display.
Refer to figure 19.
5. Exit the SETUP Mode by pressing the INPUT
Control.
Note: For convenience, a “Stored Profiles” chart
below has been provided to keep track of the
stored profiles.
Setup, con’t
The MP1100 has the ability to store up to five differ-
ent Custom Profile Settings for use with the PHONO
Inputs. The Profile Setting includes the current phono
Gain, Resistance, Capacitance Settings Sample Rate,
and Stereo/Mono Mode Settings. Once a Profile has
been stored, it can be selected by using the TRIM
Cartridge Profile Function. For additional information
on using the TRIM Profile Functions refer to “How to
Operate” page 19.
Refer to “TRIM Functions” starting on page 19 for
selecting the desired Phono, Resistance, Capacitance,
Gain, Sample Rate, Stereo/Mono Mode Settings, then
perform the following steps to assign and store to one
of the five Custom User Profile Settings:
Note: The four Default Profile Settings are permanent.
1. Press and hold in the INPUT Control to enter the
SETUP MODE. Refer to figure 2 on page 13.
2. Rotate the INPUT Control until “SETUP: User
Profile, (Hold INPUT)” appears on the Informa-
tion Display. Refer to figure 20.
3. Press and hold in the INPUT Control until
“PHONO 1->U1, (Hold INPUT to Save)” appears
Figure 15
RENAME: LINE 1
>INTGRT <
Fig ure 16
RENAME: LINE 1
>INTGRT A <
Figure 17
RENAME: LINE 1
>INTGRT AM <
Fig ure 18
RENAME: LINE 1
>INTGRT AMP<
Figure 19
+++++++SAVE+++++++
++++SUCCESSFUL++++
Profile Store
INPUT NAMES
Default Name New Name
PHONO 1
PHONO 2
PHONO 3
LINE 1
LINE 2
Figure 20
SETUP: User Profile
(Hold INPUT)
Figure 21
PHONO 1->U1
(Hold INPUT to Save)
STORED PHONO PROFILES
Prole Cartridge Type Load Capacitance Load Resistance Gain Mode Sample Rate
U1
U2
U3
U4
U5
MM* MM 50 pF 47K Ohms 46dB STEREO 96kHz
MC* MC 200 pF 1K Ohms 64dB STEREO 96kHz
MT5** MC 200 pF 1K Ohms 52dB STEREO 96kHz
MT10** MC 200 pF 400 Ohms 58dB STEREO 96kHz
* Default settings for MM (Moving Magnet) and MC (Moving Coil) Phono Cartridge Types
** Default settings for Phono Cartridges supplied with McIntosh MT5 and MT10 Turntables
