McIntyre 320 - 600 LGT and 600 Catcutting Capacity (Mild Steel 43 A)

15
320/407/500/600.41912-ENG
3.4.4. 600 LGT and 600 CAT
Single Phase Three Phase
Blade Length 608mm (23.9”) 608mm (23.9”)
Tip to Tip Opening 264mm (10.4”) 264mm (10.4”)
Shearing Height 934mm (37”) 934mm (37”)
Weight (with Oil) 1030 kg 1030 kg
Oil Capacity 200 Litres (44 Gal) 200 Litres (44 Gal)
Sound Pressure Level
(Operating Position - normal conditions)
TBC 75 +/-3 dBA
Peak Sound Pressure Level TBC 82 dBC
Sound Power Level TBC 73 +/-3 dBA
Cutting Control Single Cut - Repeating Single Cut - Repeating
Standard Power Supply 63A 1ph 230v 50hz 32A 3ph 380-415v 50hz
Motor Rating 5.5kW (7.5hp) @ 1420rpm 7.5kW (10hp) @ 1450rpm
Max System Pressure 193 Bar (2800 psi) 241 Bar (3500 psi)
Max Shear Force Up to 96 Tonnes Up to 120 Tonnes
Cutting Speed (Max Stroke) Up to 8 cycles/min Up to 8 cycles/min
Cutting Speed (40% Stroke) Up to 21 cycles/min Up to 21 cycles/min
Cutting Capacity (Mild Steel 43A):
