McIntyre 320 - Blade Guard and Protective Clothing

21
320/407/500/600.41912-ENG
4.5. The Blade Guard
The Shear is equipped with a Blade Guard which also acts as an Infeed Clamp. The
Guard is adjustable and is locked in place using the Blade Guard Handle. The Guard
should always be adjusted to leave minimum space for the feeding of material in order to
prevent the material being sheared from kicking up or skidding forward.
DonotusetheSheariftheBladeGuardis;incorrectlytted,broken,bentorifthesecuring
bolts are loose.
Do Not use the Shear without the Blade Guard in Place.
Always adjust the Guard to the lowest position.
4.6. Protective Clothing
The following Protective Clothing must be worn at all times, while operating and maintaining
the Shear:
• Steel Toe Capped Safety Boots
• Gloves and Protective Apron or Overalls
• It is recommended that a Hard Hat and Face Shield is worn.
• It is recommended that Hearing Protection is worn.
Blade
Guard
Blade Guard
Handle
