Main Menu Functions
Line 1 - Green
Line 2 - Yellow
Line 3 - Blue
Line 4 - Red
H1
H2
Farthest from Vehicle
Closest to Vehicle
(Bumper of Vehicle)
*H1 and H2 refer to the left and right distance
from the center line of the vehicle (see
Horizontal Line Set Up).
0ft. = H1
H2
4.5 ft.
This view illustrates the Left and
Right Alley Camera Set Up
H1 = 0ft.
H2
4.5 ft.
