Extreme 9" Monitor/DVR System© 2014 McNeilus Truck and Manufacturing, Inc.
28
Main Menu Functions
• G Sensor - The G-Sensor will segregate a segment of video when the G-Shock setting is triggered
(Figure 16). Set the G-Shock setting (which is the G-Shock rating) to either OFF, Low=2.0g, Mid=1.8g,
High=1.5g.
IMPORTANT
G-Sensor ratings set to High, Medium, or Low will not
allow the SD Card to loop (continuously record).
McNeilus recommends the G-Sensor rating be set to OFF
to allow the SD Card to continue to loop.
SSV Analytics allows for viewing and/or sorting separated
files triggered by a G-Shock.
• Record Time Setting - Sets the video segments (in 1 - 5 minute isolated increments) for sorting the video
when viewing the video (Figure 16).
Figure 16: G-Sensor setting and Record Time Setting for DVR.
• Factory Mode - Resets the DVR to factory default settings (Figure 17).
• FW Version No. - Displays the DVR software version (Figure 17). The current rmware version number
is TST435-0044.
Figure 17: Factory Mode reset and Software Version identication screen.
