Extreme 9" Monitor/DVR System© 2014 McNeilus Truck and Manufacturing, Inc.
46
Components for Individual Sale
Components for Individual Sale
Component Part Number
Extreme Color Monitor 9" 1487747
SSP Color Camera 1470028
Cable 3' Camera/Monitor SSP 1495023
Cable 6' Camera/Monitor SSP 1495024
Cable 9' Camera/Monitor SSP 1495025
Cable 16’ Camera/Monitor 1433196
Cable 32’ Camera/Monitor SSP 1433200
Cable 65’ Camera/Monitor 1433250
Cable 82’ Camera/Monitor SSP* 1431526
Power Accessory Harness 1511546
32GB Memory SD Card for Monitor 1453457
Triangle Driver Bit for Monitor 1484556
*When installing a hopper camera on a dump body truck, it is necessary to purchase an 82’ cable (P/N 1431526).
NOTE: Battery for the Remote Control is CR2025, which can be purchased at any local retailer.
Kit Numbers for Monitor 9"*
Cameras per System Part Number
1 camera with one 65’ cable 1487822
2 cameras with two 65’ cables 1487823
3 cameras with two 65’ cables and one 32’ cable 1487824
3 cameras with one 82' cable, one 65' cable, and one 16' cable 1487829
4 cameras with two 65’ cables, one 32’ cable, and one 16’ cable 1487825
*Each kit includes one monitor plus contents described.
NOTE: Kits are packaged for the most common applications. It may be necessary to purchase additional cables for
specic applications.
Monitor Mounting Part Number
Ram Mount Individual Components
Mount, 1.5" Ball, 2.5 Base (x2) 1476231
RAM Mount, 1.5" Ball, 2.5"L 1476232
RAM Mount, Double Socket, 1.5" Ball, 4.5"L 1489033
RAM Mount, Double Socket, 1.5" Ball, 8"L 1489034
Hex Cap Screw M5-.8X10* (x4) 1496858
Flat Washer M5x10x1* (x4) 1496859
*Use 1496858 and 1496859 when using P/N 1476231 mount.
