Rear Loader
102
Daily Lubrication Points
Lubricate Daily or Every 10 Hours
Ref. Description
No. of
Fittings
Comments
A1 Sweep Cylinder - Rod End 2 Two Cylinders - One Per Side
A2 Sweep Cylinder - Base End 2 Two Cylinders - One Per Side
B Sweep Panel Pivot Pins 2 Two Pivot Pins - One Per Side
C1 Slide Cylinder - Rod End 2 Two Cylinders - One Per Side
C2 Slide Cylinder - Base End 2 Two Cylinders - One Per Side
D1 Reeving Cable Cylinder Rod End Pulleys - Front (Optional) 2 Two Pulleys - One Per Side
D2 Reeving Cable Cylinder Base End Pulleys - Rear (Optional) 2 Two Pulleys - One Horizontal, One Vertical
E Reeving Cable Guide Pulleys (Optional) 2 Two Pulleys
F Tipper Cylinder - Base End (Optional) 2 Two Cylinders - One Per Side
Preventive Maintenance
