© 2008 McNeilus Truck and Manufacturing, Inc.
Rear Loader
35
General Information
1.3 T-Type Container Specications
1.3.1 Type T Container 3 yd
3
or Less Capacity
Only lift containers that are compatible with ANSI Z245.60-
2008 type T containers of 3 yd
3
or less capacity. Before lifting,
ensure that the container meets the dimensional requirements
as described in the following table and detailed in Figure 3.
No. Description Specication
1
Total length of the trunnion bar including
washers if provided. If washers are
provided, their diameter should be 2-1/4 in.
Min: 77-1/2 in.
Max: 78 in.
2
Width of container and all the supporting
gussets attached to the trunnion bar.
Max: 72 in.
3
Width of the container body including
structural supporting side members (“side
rails”). This dimension excludes handles
and gusset supports.
Max: 66 in.
4
Diameter of trunnion bar at latch-up points. Min: 1-1/4 in.
Max: 1-3/4 in.
5
The distance from the center line of the
trunnion bar to the ground. The top of the
trunnion bar should coincide with the top
of the container on the side where the
trunnion bar is located.
Min: 45 in.
Max: 49 in.
No. Description Specication
6
Horizontal distances from the lower
front edge of the container body to a
perpendicular originating at the upper
front edge of the container (excluding the
trunnion bar). NOTE: This distance is to be
measured at ground level.
Min: 2 in.
7
Vertical distance between the uppermost
part of the handle on the side of the
container and the centerline of the
trunnion bar.
Max: 3 in.
8
The distance between the center line of
the trunnion bar and the front of the lift
point. NOTE: Lift points should not extend
beyond dimension B out from the side of
the container.
Min: 10 in.
Max: 17 in.
9
The maximum diameter (thickness) of an
attachment through which a cable may be
hooked to the container.
Max: 1-1/4 in.
10
The distance from inside of side handle to
the outside of the container.
Min: 2 in.
