© 2008 McNeilus Truck and Manufacturing, Inc.
Rear Loader
50
Operation
2.4 Turnbuckle and Optional Hydraulic
Tailgate Lock Operation
NOTE
The warble alarm sounds when the tailgate
is opening and remains on until the tailgate
is closed.
The alarm does not sound if the ignition
switch is OFF or any of the E-STOP buttons
are pressed down.
2.4.1 Trucks Without Tag Axle (Turnbuckle)
One turnbuckle is present on each side of the lower rear
tailgate. These turnbuckles are safety devices that clamp
down and secure the tailgate to the collector body.
DANGER
Be sure all individuals are clear of the
tailgate area before opening the tailgate.
Remain attentive at all times.
Be sure you have adequate clearance above
the tailgate to prevent contact with buildings
or electrical lines.
Serious injury or death may result if
someone is caught in the path of the tailgate.
1. To unlock the turnbuckle, turn the handle
counterclockwise several times until it is loose.
2. Push the turnbuckle down to allow the tailgate to be
opened.
3. Repeat Steps 1 and 2 for the turnbuckle on the opposite
side of the vehicle.
4. Operate the tailgate controls to hydraulically open and
close the tailgate.
5. To lock the turnbuckle once the tailgate is closed, pull
the turnbuckle up and into the slot.
6. Turn the handle clockwise several times to clamp and
lock it in position.
7. Repeat Steps 5 and 6 on the opposite side of the
tailgate.
