Rear Loader
52
Operation
2.4.3 Hydraulic Tailgate Locks (Optional)
An optional hydraulic tailgate latch is available. The latches
are installed on both sides of the tailgate. The tailgate lock
function is controlled by a tailgate lock control lever usually
located at the outside front controls.
2.4.3.1 Unlock Tailgate (Hydraulic Locks)
1. To unlock tailgate, remove the pin (Figure 19, Item 1)
from latch (Figure 19, Item 2) and swing latch away from
tailgate lock (Figure 19, Item 3). Repeat this step for the
other side.
2. Lift up and hold control lever lock for tailgate lock control
lever.
3. Pull and hold the tailgate lock control lever to unlock the
tailgate lock.
1
2
3
Figure 19
To Next Page
