Rear Loader
34
General Information
1.2 Curb Side View
8
11
10
13
9
12
16
15
14
With Tag Axle
Ref No. System Description Ref No. System Description
8 Slide Panel 13 Commercial Container Tipper Bar (Optional)
9 Sweep Panel 14 Residential Cart Tipper (Optional)
10 Outside Rear Controls 15 Reeving Cylinder or Winch (Optional)
11 Hydraulic Reservoir - Position May Vary 16 Tailgate with Tag Axle (Optional)
12 Commercial Container Guide and Locks (Optional)
