McNeilus XC Rear Loader - Control Functions; E-STOP (Emergency Stop) Function

© 2008 McNeilus Truck and Manufacturing, Inc.
Rear Loader
46
Operation
2.0 Control Functions
2.1 E-STOP (Emergency Stop) Function
The E-STOP button is red and is located on the cab control
box (Figure 13). In addition, your Rear Loader may be ordered
with a tailgate E-STOP(s) (Figure 14), which is located on the
tailgate on either or both sides. Pressing any E-STOP button
IMMEDIATELY DISABLES refuse vehicle functions requiring
hydraulic pressure.
WARNING
Never stand or position yourself under any
raised hydraulic component. Moving the
control lever of any raised hydraulic
component will cause the component to
suddenly lower whether the E-STOP is
pressed or not.
Serious personal injury or death may occur.
NOTE
The E-STOP button remains in a locked
DOWN position until it is manually released.
1
Figure 13
1
Figure 14
