McQuay MDM Series User Manual

14
The Motor Power Table
MOTOR POWER (kW)
ESP(300Pa) ESP(500Pa)MODEL MDM
4 ROWS 6 ROWS 8ROWS 4 ROWS 6 ROWS 8ROWS
0306
0.75 1.1 1.1 1.1 1.1 1.1
0308
0.55x2 0.55x2 0.75x2 0.75x2 0.75x2 1.1x2
0408
1.5 2.2 2.2 2.2 2.2 3
0410
2.2 3 4 4
0509
2.2 2.2 3 3 3 4
0510
2.2 3 3 3 4 4
0511
3 3 4 4 4 4
0610
4 4 4 4 5.5 5.5
0611
4 4 5.5 5.5 5.5 5.5
0612
4 4 5.5 5.5 5.5 5.5
0711
4 5.5 5.5 5.5 7.5 7.5
0712
4 5.5 7.5 7.5 7.5 7.5
0713
5.5 5.5 7.5 7.5 7.5 11
0812
5.5 7.5 7.5 7.5 7.5 11
0813
5.5 7.5 7.5 7.5 11 11
0913
7.5 7.5 11 11 11 11
0914
7.5 7.5 11 11 11 11
1014
7.5 11 11 11 11 15
1015
11 11 11 11 11 15
1115
11 11 11 11 15 15
1116
11 11 11 11 15 15
1216
11 11 15 15 15 18.5
1217
11 15 15 15 18.5 18.5
1317
11 15 15 15 18.5 22
1417
15 15 18.5 18.5 18.5 22
1518
15 18.5 18.5 18.5 22 22
1618
15 18.5 22 22 22 30
1719
18.5 22 22 22 30 30
1820
22 22 30 30 30 30
1822
22 30 30 30 37 37
1825
30 30 37 37 37 37
1826
37 37 37 37 45 45
