McQuay MDM Series User Manual

13
The Heating Performance Data Table Based On Fresh-Air Mode
RETURN-AIR MODE (2 ROWS / 12 FPI)
FACE VELOCITY - 2.5m/s FACE VELOCITY - 2.75m/s
A.F W.F W.P.D A.P.D H.C A.F W.F W.P.D A.P.D H.C
MODEL
MDM
CIRCUIT
PIPE
connection
BSP
m³/h l/s kPa Pa kW m³/h l/s kPa Pa kW
0306
H 2.5
2030 0.76 5.2 80.1 32 2233 0.81 5.8 94 34
0308
H 2.5
2908 1.13 12.7 80.1 47 3199 1.20 14.2 94 49
0408
H 2.5
4362 1.66 15.3 80.1 70 4798 1.77 17.2 94 74
0410
H 2.5
5678 2.19 28.6 80.1 92 6246 2.33 32.0 94 98
0509
H 2.5
6693 2.56 25.2 80.1 108 7363 2.75 28.8 94 114
0510
H 2.5
7571 2.93 33.9 80.1 122 8328 3.12 38.1 94 130
0511
H 2.5
8449 3.26 43.2 80.1 137 9294 3.50 49.3 94 146
0610
H 2.5
9464 3.65 38.9 80.1 153 10410 3.90 44.0 94 163
0611
H 2.5
10561 4.10 50.2 80.1 171 11617 4.35 56.1 94 183
0612
H 2.5
11659 4.55 63.2 80.1 190 12824 4.85 71.2 94 202
0711
S 2.5
12674 4.70 14.0 80.1 196 13941 5.00 15.8 94 209
0712
S 2.5
13990 5.20 17.3 80.1 218 15389 5.55 19.6 94 232
0713
S 2.5
15307 5.80 21.7 80.1 240 16838 6.10 23.9 94 255
0812
S 2.5
16322 6.10 19.8 80.1 255 17954 6.50 22.4 94 271
0813
S 2.5
17858 6.70 24.1 80.1 280 19644 7.10 26.9 94 298
0913
S 2.5
20409 7.70 29.3 80.1 320 22450 8.10 32.2 94 340
0914
S 3
22165 8.40 35.0 80.1 350 24382 8.90 39.1 94 372
1014
S 2.5
24936 9.40 20.5 80.1 393 27429 10.00 23.1 94 418
1015
S 2.5
26911 10.20 24.4 80.1 426 29602 10.80 27.2 94 453
1115
S 2.5
29901 11.30 26.3 80.1 474 32891 12.00 29.4 94 503
1116
S 2.5
32095 12.20 30.9 80.1 510 35305 13.00 34.9 94 543
1216
S 2.5
35305 13.50 33.6 80.1 562 38835 14.30 37.5 94 597
1217
S 2.5
37719 14.40 38.6 80.1 602 41491 15.30 43.3 94 640
1317
S 2.5
41148 15.70 41.2 80.1 657 45263 16.70 46.3 94 698
1417
S 2.5
44577 17.00 43.7 80.1 711 49035 18.10 49.3 94 765
1518
H 2.5
49734 19.00 42.0 80.1 795 54708 20.10 46.7 94 845
1618
H 2
53287 20.40 27.6 80.1 852 58615 21.60 30.7 94 905
1719
H 2
60350 23.20 33.4 80.1 968 66385 24.60 37.3 94 1028
1820
H 2
67853 26.00 39.6 80.1 1090 74638 28.00 45.4 94 1166
1822
H 2
75315 29.00 50.3 80.1 1215 82846 31.00 56.8 94 1293
1825
S 3
86507 32.30 31.7 80.1 1350 95157 34.20 35.3 94 1433
1826
S 3
90238 33.80 34.7 80.1 1412 99261 36.00 39.2 94 1501
Notes:
1) Entering Dry Bulb Temperature (EDB): 0°C
2) Entering Water Temperature: 60°C
3) Leaving Water Temperature: 50°C
