McQuay MDM Series User Manual

12
The Heating Performance Data Table Based On Return-Air Mode
RETURN-AIR MODE (2 ROWS / 12 FPI)
FACE VELOCITY - 2.5m/s FACE VELOCITY - 2.75m/s
A.F W.F W.P.D A.P.D H.C A.F W.F W.P.D A.P.D H.C
MODEL
MDM
CIRCUIT
PIPE
connection
BSP
m³/h l/s kPa Pa kW m³/h l/s kPa Pa kW
0306
H 2.5
2030 0.32 1.0 80.1 13 2233 0.335 1.1 94 14
0308
H 2.5
2908 0.48 2.7 80.1 20 3199 0.510 3.0 94 21
0408
H 2.5
4362 0.72 3.2 80.1 30 4798 0.760 3.6 94 32
0410
H 2.5
5678 0.96 6.2 80.1 40 6246 1.000 6.7 94 42
0509
H 2.5
6693 1.10 5.2 80.1 47 7363 1.200 6.1 94 50
0510
H 2.5
7571 1.28 7.3 80.1 53 8328 1.360 8.1 94 57
0511
H 2.5
8449 1.45 9.6 80.1 60 9294 1.540 10.7 94 64
0610
H 2.5
9464 1.60 8.3 80.1 67 10410 1.700 9.3 94 71
0611
H 2.5
10561 1.80 10.8 80.1 75 11617 1.920 12.1 94 80
0612
H 2.5
11659 2.00 13.6 80.1 84 12824 2.120 15.2 94 89
0711
H 2.5
12674 2.15 12.0 80.1 90 13941 2.300 13.6 94 96
0712
H 2.5
13990 2.40 15.2 80.1 101 15389 2.560 17.2 94 107
0713
H 2.5
13507 2.64 18.8 80.1 111 16838 2.800 21.0 94 118
0812
H 2.5
16322 2.80 16.8 80.1 117 17954 3.000 19.1 94 125
0813
H 2.5
17858 3.10 21.0 80.1 129 19644 3.300 23.6 94 137
0913
H 2.0
20409 3.55 15.4 80.1 148 22450 3.750 17.0 94 157
0914
H 2.0
22165 3.85 18.5 80.1 161 24382 4.100 20.7 94 171
1014
H 2.5
24936 4.35 19.7 80.0 182 27429 4.600 21.9 94 193
1015
H 2.5
26911 4.70 23.6 80.1 192 29602 5.000 26.5 94 203
1115
H 2.5
29901 5.20 24.7 80.1 218 32891 5.550 27.9 94 232
1116
H 2.5
32095 5.65 29.8 80.1 236 35305 6.000 33.3 94 251
1216
H 2.5
35305 6.20 31.8 80.1 259 38835 6.600 35.1 94 276
1217
H 2.5
37719 6.65 36.6 80.1 278 41491 7.100 41.3 94 296
1317
H 2.5
41148 7.25 38.4 80.1 303 45263 7.700 42.9 94 322
1417
H 2.5
44577 7.90 40.6 80.1 329 49035 8.400 45.5 94 350
1518
H 2.5
49734 8.30 8.8 80.1 346 54708 8.800 9.8 94 368
1618
H 2.0
53287 8.90 6.0 80.1 371 58615 9.400 6.7 94 394
1719
H 2.0
60350 10.10 7.3 80.1 423 66385 10.800 8.2 94 450
1820
H 2.0
67853 11.50 8.8 80.1 479 74638 12.200 9.8 94 508
1822
H 2.0
75315 12.80 11.2 80.1 536 82846 13.600 12.5 94 569
1825
H 2.0
86507 14.90 15.6 80.1 622 95157 15.900 17.6 94 662
1826
H 2.0
90238 15.60 17.3 80.1 651 99261 16.600 19.4 94 692
Notes:
1) Entering Dry Bulb Temperature (EDB): 21°C
2) Entering Water Temperature: 60°C
3) Leaving Water Temperature: 50°C
