McQuay MDM Series User Manual

11
The Cooling Performance Data Table Based On Fresh-Air Mode (III)
COIL TYPE (8 ROWS / 12 FPI)
FACE VELOCITY - 2.5m/s FACE VELOCITY - 2.75m/s
A.F W.F W.P.D S.C T.C A.F W.F W.P.D S.C T.C
MODEL CIRCUIT
PIPE
connection
BSP
m³/h l/s kPa kW kW m³/h l/s kPa kW kW
0306
L 1.5
2030 2.00 38.5 17.36 42.33 2294 2.18 44.8 18.81 45.98
0308
S 1.5
2908 2.85 46.1 24.58 60.24 3259 3.10 53.6 26.64 65.42
0408
M 2.5
4362 4.10 15.2 35.01 86.36 4888 4.50 18.0 37.99 93.83
0410
M 2.5
5678 5.50 28.9 46.72 115.27 6337 6.00 33.8 50.68 125.21
0509
M 2.5
6693 6.40 25.9 54.35 134.34 7483 6.90 29.7 58.76 145.72
0510
M 2.5
7571 7.40 35.4 62.20 153.70 8449 8.00 40.8 67.41 166.78
0511
M 2.5
8449 8.30 45.5 69.93 172.76 9415 8.90 51.7 75.76 187.43
0610
M 2.5
9464 9.20 41.9 77.57 191.87 10561 10.00 48.9 84.13 208.34
0611
M 2.5
10561 10.30 53.5 87.21 215.64 11768 11.20 62.4 94.67 234.36
0612
D 2.5
11659 11.20 44.4 94.38 233.73 12976 12.00 50.5 102.10 253.15
0711
D 2.5
12674 12.00 43.4 101.41 251.39 14122 13.10 51.3 109.91 272.71
0712
D 2.5
13990 13.50 55.3 113.23 280.55 15571 14.60 64.1 122.67 304.28
0713
D 2.5
15307 14.70 66.2 124.64 308.74 17019 16.00 77.7 135.23 335.32
0812
D 2.5
16322 15.70 66.6 131.95 327.08 18165 17.00 77.5 142.98 354.79
0813
D 2.5
17858 17.30 81.4 145.49 360.49 19855 18.60 93.4 157.60 390.93
0913
D 3.0
20409 19.60 84.0 166.01 411.48 22692 21.20 97.5 179.97 446.55
0914
D 3.0
22165 21.50 101.6 181.59 449.89 24624 23.30 118.4 197.04 488.68
1014
D 2.5
24936 24.00 57.6 204.03 505.61 27701 26.50 69.3 221.93 550.47
1015
D 2.5
26911 26.00 68.4 221.41 548.45 29874 28.40 80.7 240.47 596.31
1115
D 2.5
29901 29.20 77.8 246.26 610.04 33193 31.60 90.3 267.18 662.61
1116
D 2.5
32095 31.50 91.6 265.61 657.74 35607 33.80 104.4 287.98 714.00
1216
D 2.5
35305 34.30 99.5 291.80 722.72 39168 37.50 117.7 317.05 786.09
1217
D 2.5
37719 37.00 116.8 313.24 775.51 41823 40.00 135.2 340.01 842.79
1317
D 2.5
41148 40.50 129.6 341.79 846.23 45625 44.00 151.5 371.22 920.14
1417
D 2.5
44577 44.00 143.0 370.34 916.97 49427 48.00 168.7 402.42 997.49
1518
D 2.5
49734 45.50 34.5 384.19 955.61 55130 49.00 39.8 415.71 1034.56
1618
D 3.0
53287 49.00 32.9 411.98 1024.73 59068 53.00 38.3 446.15 1110.33
1719
D 3.0
60350 56.00 42.2 470.42 1169.79 66868 61.00 49.7 510.28 1269.65
1820
D 3.0
67853 63.00 52.5 532.01 1322.66 75151 68.00 60.7 576.42 1434.07
1822
D 3.0
75315 72.00 68.7 600.24 1491.01 83359 77.00 78.1 648.55 1612.63
1825
D 3.0
86507 83.00 92.0 698.24 1733.03 95670 90.00 107.4 757.35 1881.52
1826
D 3.0
90238 86.00 99.1 730.19 1812.01 99774 94.00 117.4 793.01 1969.65
Notes:
1) Entering Dry Bulb Temperature (EDB): 34°C
2) Entering Wet Bulb Temperature: 28°C
3) Entering Water Temperature: 7°C
4) Leaving Water Temperature: 12°C
