McQuay MDM Series User Manual

10
The Cooling Performance Data Table Based On Fresh-Air Mode (II)
COIL TYPE (6 ROWS / 12 FPI)
FACE VELOCITY - 2.5m/s FACE VELOCITY - 2.75m/s
A.F W.F W.P.D S.C T.C A.F W.F W.P.D S.C T.C
MODEL
MDM
CIRCUIT
PIPE
connectio
n BSP
m³/h l/s kPa kW kW m³/h l/s kPa kW kW
0306
L 1.5
2030 1.80 25.1 15.72 38.43 2233 1.95 29.0 16.94 41.46
0308
S 1.5
2908 2.60 31.8 22.36 54.95 3199 2.80 36.3 24.08 59.24
0408
S 1.5
4362 3.85 41.7 33.11 81.75 4798 4.20 49.0 35.78 88.40
0410
M 2.5
5678 5.00 20.1 42.11 104.16 6246 5.30 22.3 45.20 111.81
0509
M 2.5
6693 5.70 17.9 48.47 119.95 7362 6.20 20.9 52.34 129.52
0510
M 2.5
7571 6.60 24.4 55.89 138.50 8328 7.20 28.7 60.39 149.66
0511
M 2.5
8449 7.50 32.1 63.17 156.64 9294 8.00 36.2 68.05 168.76
0610
M 2.5
9464 8.20 29.6 69.61 172.68 10410 8.90 34.5 75.17 186.46
0611
M 2.5
10561 9.40 39.5 78.87 195.76 11617 10.00 44.3 84.93 210.82
0612
M 2.5
11659 10.40 49.1 88.01 218.51 12825 11.30 57.3 94.97 235.86
0711
M 2.5
12674 11.30 47.8 94.58 234.88 13941 12.00 53.5 101.82 252.89
0712
M 2.5
13990 12.50 59.2 105.54 262.18 15389 13.40 67.4 113.65 282.39
0713
M 2.5
15307 13.70 72.0 116.40 289.19 16838 14.80 83.2 125.46 311.83
0812
M 2.5
16322 14.50 69.5 122.94 305.51 17954 15.60 79.8 132.45 329.25
0813
M 2.5
17858 16.00 85.5 135.74 337.35 19644 17.20 97.9 146.21 363.51
0913
M 2.5
20409 18.30 82.2 155.08 385.52 22450 19.70 94.4 167.08 415.51
0914
M 3.0
22165 20.00 99.2 169.70 421.86 24382 21.80 116.6 183.49 456.34
1014
M 2.5
24936 22.60 67.1 190.98 474.83 27430 24.40 77.3 206.20 512.93
1015
M 2.5
26911 24.60 80.8 207.52 515.91 29602 26.50 92.7 224.06 557.34
1115
M 2.5
29901 27.30 88.4 230.48 573.08 32891 29.30 100.7 248.72 618.78
1116
M 2.5
32095 29.30 103.3 248.62 618.11 35305 31.80 120.2 268.77 668.61
1216
M 2.5
35305 32.50 114.6 273.73 680.58 38836 35.00 131.4 295.62 735.49
1217
M 2.5
37719 35.00 134.5 293.98 730.81 41491 38.00 156.7 317.93 790.89
1317
M 2.5
41148 38.00 144.9 320.47 796.75 45263 41.00 167.0 346.29 861.54
1417
M 2.5
44577 41.00 156.0 346.96 862.70 49035 45.00 185.8 375.74 934.83
1518
M 2.5
49734 43.00 37.3 358.36 891.88 54707 46.00 42.4 385.99 960.19
1618
M 3.0
53287 46.00 32.4 383.81 955.27 58616 49.00 36.5 413.05 1027.52
1719
M 3.0
60350 52.00 40.3 437.64 1089.48 66385 56.00 46.3 472.09 1174.86
1820
M 3.0
67853 59.00 50.5 495.99 1234.94 74638 63.00 57.1 534.37 1330.17
1822
M 3.0
75315 66.00 63.7 557.29 1387.66 82847 71.00 73.1 601.54 1497.85
1825
M 3.0
86507 77.00 87.8 651.51 1622.04 95158 83.00 101.2 702.19 1748.69
1826
M 3.0
90238 81.00 97.6 683.07 1700.47 99262 87.00 111.7 736.94 1835.19
Notes:
1) Entering Dry Bulb Temperature (EDB): 34°C
2) Entering Wet Bulb Temperature: 28°C
3) Entering Water Temperature: 7°C
4) Leaving Water Temperature: 12°C
