McQuay MDM Series User Manual

9
The Cooling Performance Data Table Based On Fresh-Air Mode (I)
COIL TYPE (4 ROWS / 12 FPI)
FACE VELOCITY - 2.5m/s FACE VELOCITY - 2.75m/s
A.F W.F W.P.D S.C T.C A.F W.F W.P.D S.C T.C
MODEL
MDM
CIRCUIT
PIPE
connection
BSP
m³/h l/s kPa kW kW m³/h l/s kPa kW kW
0306
H 1.5 2030 1.60 36.6 13.89 33.62 2233 1.68 39.8 14.81 35.80
0308
L 1.5 2908 2.20 31.0 19.28 46.90 3199 2.35 34.8 20.64 50.10
0408
L 1.5 4362 3.30 39.7 28.63 69.98 4798 3.52 44.6 30.66 74.74
0410
S 1.5 5678 4.25 44.7 36.73 89.93 6246 4.60 51.7 39.46 96.34
0509
L 2.0 6693 5.16 45.0 44.48 109.40 7362 5.65 53.4 47.84 117.43
0510
L 2.0 7571 5.95 61.5 50.96 125.65 8328 6.40 70.0 54.69 134.57
0511
S 2.0 8449 6.50 44.0 55.44 136.42 9294 7.00 50.4 59.51 146.09
0610
S 2.0 9464 7.10 39.7 61.00 149.86 10410 7.60 45.0 65.41 160.21
0611
S 2.0 10561 8.10 52.5 69.13 170.29 11617 8.60 58.6 74.03 181.83
0612
M 2.5 11659 8.40 27.9 72.22 176.64 12825 9.00 31.8 77.52 188.87
0711
S 2.5 12574 9.80 52.5 82.98 204.59 13941 10.40 58.5 88.86 218.44
0712
M 2.5 13990 10.00 33.9 86.41 211.44 15389 10.80 39.2 92.93 226.54
0713
M 2.5 15307 11.40 44.4 96.48 236.95 16838 12.00 48.8 102.93 251.67
0812
M 2.5 16322 11.70 41.3 100.79 246.78 17954 12.50 46.8 108.15 263.73
0813
M 2.5 17858 13.00 51.3 111.94 274.87 19644 13.90 58.2 119.84 293.06
0913
M 3.0 20409 15.00 49.9 128.12 314.79 22450 16.00 56.4 137.08 335.79
0914
M 3.0 22165 16.50 60.8 140.92 346.99 24382 17.80 70.3 151.42 371.64
1014
M 2.5 24936 18.60 38.7 158.54 390.47 27430 19.70 43.1 169.73 416.46
1015
M 2.5 26911 20.50 47.6 173.32 427.68 29602 22.00 54.3 186.03 457.64
1115
M 2.5 29901 22.50 51.8 192.07 473.90 32891 24.00 58.4 205.92 506.45
1116
D 2.5 32095 23.10 41.1 198.23 486.53 35305 24.80 47.0 212.75 520.05
1216
D 2.5 35305 25.50 46.8 218.17 535.60 38836 27.20 52.9 233.85 571.63
1217
D 2.5 37719 27.50 54.7 235.63 579.52 41491 29.20 61.3 251.91 616.83
1317
D 2.5 41148 29.90 60.9 256.83 631.66 45263 32.00 69.3 275.01 673.55
1417
D 2.5 44577 32.50 68.3 278.38 684.80 49035 34.50 76.6 297.61 728.85
1518
S 2.5 49734 37.00 38.6 313.26 771.67 54707 39.00 42.5 335.07 822.01
1618
S 3.0 53287 40.00 32.0 336.20 828.44 58616 42.00 35.0 359.34 881.75
1719
S 3.0 60350 45.00 38.6 383.08 944.88 66385 48.00 43.5 449.58 1009.53
1820
S 3.0 67853 52.00 49.2 435.81 1076.83 74638 55.00 54.6 466.60 1148.77
1822
M 3.0 75315 54.00 39.1 465.52 1118.62 82847 58.00 44.0 492.09 1201.39
1825
M 3.0 86507 63.00 53.7 537.52 1322.63 95158 68.00 62.1 576.65 1413.36
1826
D 3.0 90238 62.00 47.0 532.58 1298.97 99262 66.00 53.0 570.96 1385.09
Notes:
1) Entering Dry Bulb Temperature (EDB): 34°C
2) Entering Wet Bulb Temperature: 28°C
3) Entering Water Temperature: 7°C
4) Leaving Water Temperature: 12°C
