McQuay MDM Series User Manual

8
The Cooling Performance Data Table Based On Return-Air Mode (III)
COIL TYPE (8 ROWS / 12 FPI)
FACE VELOCITY - 2.5m/s FACE VELOCITY - 2.75m/s
A.F W.F W.P.D S.C T.C A.F W.F W.P.D S.C T.C
MODEL
MDM
CIRCUIT
PIPE
connection
BSP
m³/h l/s kPa kW kW m³/h l/s kPa kW kW
0306
H 1.5
2030 0.93 27.1 13.00 20.00 2233 1.00 30.8 14.10 21.61
0308
H 1.5
2908 1.38 66.3 18.72 29.21 3199 1.48 74.8 20.33 31.62
0408
L 1.5
4362 2.00 25.4 27.07 41.90 4798 2.15 29.4 29.41 45.32
0410
L 1.5
5678 2.65 48.4 35.61 55.63 6246 2.85 55.0 38.72 60.25
0509
L 2.0
6693 2.60 23.5 39.98 61.64 7362 2.80 26.7 43.43 66.62
0510
S 2.0
7571 3.40 21.1 46.24 71.62 8328 3.70 24.5 50.33 77.67
0511
S 2.0
8449 3.80 27.2 51.87 80.65 9294 4.20 32.5 56.59 87.75
0610
S 2.0
9464 4.30 24.0 57.76 89.60 10410 4.60 27.1 62.74 96.85
0611
S 2.0
10561 4.80 30.7 64.79 100.88 11617 5.20 35.5 70.52 109.36
0612
S 2.0
11659 5.30 38.5 71.84 112.19 12825 5.80 45.3 78.31 121.88
0711
S 2.5
12674 5.70 29.9 77.55 120.73 13941 6.20 34.7 84.46 130.97
0712
S 2.5
13990 6.50 39.7 86.34 135.03 15389 7.00 45.3 93.94 146.30
0713
S 2.5
15307 7.00 47.4 94.64 148.24 16838 7.60 54.9 103.09 160.87
0812
M 2.5
16322 7.10 20.1 96.88 149.02 17954 7.60 22.8 105.23 160.94
0813
M 2.5
17858 7.80 24.6 106.71 164.78 19644 8.50 28.9 116.23 178.74
0913
M 3.0
20409 9.00 24.2 122.05 188.63 22450 9.80 28.4 132.94 204.59
0914
M 3.0
22165 10.00 30.3 133.67 207.52 24382 10.80 34.9 145.45 224.76
1014
M 2.5
24936 11.20 21.8 150.23 233.18 27430 12.00 24.6 163.28 252.14
1015
M 2.5
26911 12.00 25.5 162.71 253.07 29602 13.00 29.5 177.14 274.33
1115
M 2.5
29901 13.40 27.7 180.85 281.41 32891 14.50 32.0 196.87 304.99
1116
M 2.5
32095 14.50 33.0 195.11 304.39 35305 15.80 38.6 212.62 330.42
1216
M 2.5
35305 16.00 35.6 214.66 334.97 38836 17.50 41.9 234.04 363.84
1217
M 2.5
37719 17.00 40.9 229.98 359.44 41491 18.50 47.7 250.60 390.15
1317
M 2.5
41148 19.00 45.7 251.60 393.75 45263 20.50 52.6 273.89 426.80
1417
M 2.5
44577 20.50 48.5 272.39 426.22 49035 22.00 55.3 296.31 461.53
1518
L 2.5
49734 23.00 41.0 304.90 477.85 54707 25.00 47.5 331.94 518.05
1618
L 2.5
53287 24.50 41.7 326.10 510.78 58616 26.50 48.0 355.14 553.96
1719
L 2.5
60350 27.50 48.4 369.71 579.48 66385 30.00 56.6 403.39 630.20
1820
L 2.5
67853 31.50 58.5 417.96 656.76 74638 34.00 67.1 455.19 712.40
1822
S 3.0
75315 34.00 35.0 457.14 714.25 82847 37.00 40.8 498.15 775.26
1825
S 3.0
86507 40.00 50.2 530.48 832.70 95158 43.00 57.1 577.38 902.44
1826
S 3.0
90238 42.00 55.9 554.89 872.10 99262 45.00 63.3 603.80 944.84
Notes:
1) Entering Dry Bulb Temperature (EDB): 27°C
2) Entering Wet Bulb Temperature: 19.5°C
3) Entering Water Temperature: 7°C
4) Leaving Water Temperature: 12°C
