McQuay MDM Series User Manual

7
The Cooling Performance Data Table Based On Return-Air Mode (II)
COIL TYPE (6 ROWS / 12 FPI)
FACE VELOCITY - 2.5m/s FACE VELOCITY - 2.75m/s
A.F W.F W.P.D S.C T.C A.F W.F W.P.D S.C T.C
MODEL
MDM
CIRCUIT
PIPE
connection
BSP
m³/h l/s kPa kW kW m³/h l/s kPa kW kW
0306
H 1.5
2030 0.83 16.9 12.03 17.78 2233 0.90 19.5 13.03 19.16
0308
H 1.5
2908 1.20 39.5 17.38 26.20 3199 1.32 46.6 18.89 28.36
0408
H 1.5
4362 1.87 45.4 25.95 39.36 4798 2.00 51.1 28.11 42.37
0410
L 1.5
5678 2.35 31.3 33.01 49.77 6246 2.52 35.5 35.78 53.59
0509
L 2.0
6693 2.80 20.9 38.58 57.96 7362 2.95 22.9 41.71 62.14
0510
L 2.0
7571 3.15 27.5 43.88 66.26 8328 3.40 31.4 47.63 71.47
0511
L 2.0
8449 3.60 37.0 49.39 75.05 9294 3.80 40.6 53.45 80.60
0610
L 2.0
9464 3.90 29.2 54.65 82.53 10410 4.20 33.3 59.30 88.98
0611
L 2.0
10561 4.40 38.3 61.41 93.24 11617 4.80 44.7 66.78 100.83
0612
L 2.0
11659 5.00 50.7 68.38 104.41 12825 5.40 58.1 74.27 112.72
0711
L 2.5
12674 5.30 38.4 73.63 111.88 13941 5.80 45.0 80.12 121.10
0712
L 2.5
13990 5.90 49.0 82.78 124.76 15389 6.40 56.6 88.87 134.81
0713
S 2.5
15307 6.30 32.1 87.83 132.87 16838 6.80 36.8 95.38 143.35
0812
S 2.5
16322 6.60 28.0 92.82 139.70 17954 7.20 32.8 100.95 151.07
0813
S 2.5
17858 7.40 35.8 102.49 155.16 19644 7.90 40.3 111.12 167.00
0913
S 3.0
20409 8.40 32.3 116.94 176.99 22450 9.60 37.3 127.07 191.13
0914
S 3.0
22165 9.20 39.6 127.77 194.13 24382 9.90 45.2 138.72 209.38
1014
S 2.0
24936 10.50 38.5 143.97 219.01 27430 11.20 43.3 156.12 235.77
1015
S 2.0
26911 11.50 47.2 156.35 238.72 29602 12.30 53.3 169.62 257.23
1115
M 2.5
29901 12.00 19.3 166.79 249.27 32891 12.90 22.0 181.03 268.53
1116
M 2.5
32095 13.00 23.0 180.26 270.57 35305 14.00 26.3 195.71 291.68
1216
M 2.5
35305 14.00 23.9 197.58 296.05 38836 15.20 27.8 214.79 319.77
1217
M 2.5
37719 15.30 28.9 212.86 320.56 41491 16.40 32.9 230.96 245.24
1317
M 2.5
41148 16.25 30.6 231.75 348.71 45263 18.00 35.9 252.14 377.13
1417
M 2.5
44577 18.00 33.4 251.30 378.35 49035 19.50 38.7 273.11 408.52
1518
L 2.5
49734 20.50 26.8 281.91 425.83 54707 22.00 30.4 305.95 458.85
1618
L 2.5
53287 22.00 27.8 307.08 456.38 58616 23.60 31.6 327.83 491.72
1719
L 2.5
60350 25.00 33.2 343.66 520.65 66385 27.00 38.1 373.35 561.94
1820
L 2.5
67853 28.00 38.7 387.58 588.24 74638 30.00 43.8 420.59 633.92
1822
L 2.5
75315 32.00 51.6 434.78 663.85 82847 34.00 57.6 471.32 714.33
1825
S 3.0
86507 36.00 34.3 492.30 746.61 95158 38.00 37.8 533.05 801.68
1826
S 3.0
90238 37.00 36.7 513.90 779.77 99262 40.00 42.3 558.40 841.87
Notes:
1) Entering Dry Bulb Temperature (EDB): 27°C
2) Entering Wet Bulb Temperature: 19.5°C
3) Entering Water Temperature: 7°C
4) Leaving Water Temperature: 12°C
