McQuay MDM Series User Manual

6
The Cooling Performance Data Table Based On Return-Air Mode (I)
COIL TYPE (4 ROWS / 12 FPI)
FACE VELOCITY - 2.5m/s FACE VELOCITY - 2.75m/s
A.F W.F W.P.D S.C T.C A.F W.F W.P.D S.C T.C
MODEL
MDM
CIRCUIT
PIPE
connection
BSP
m³/h l/s kPa kW kW m³/h l/s kPa kW kW
0306
H 1.5
2030 0.64 7.3 10.33 13.82 2233 0.68 8.1 11.11 14.71
0308
H 1.5
2908 1.00 19.6 15.00 21.25 3199 1.05 21.3 16.36 22.58
0408
H 1.5
4362 1.48 21.4 22.49 31.39 4798 1.58 24.0 24.25 33.53
0410
H 1.5
5678 2.00 41.7 29.84 42.56 6246 2.15 47.4 32.22 45.58
0509
H 1.5
6693 2.35 34.8 34.78 49.28 7362 2.50 38.9 37.49 52.60
0510
H 1.5
7571 2.70 47.2 39.71 56.78 8328 2.90 53.6 42.94 60.96
0511
L 2.0
8449 2.80 17.1 42.57 59.32 9294 3.00 19.3 45.97 63.46
0610
H 1.5
9464 3.35 52.1 49.44 70.68 10410 3.55 57.8 53.29 75.44
0611
L 2.0
10561 3.50 18.8 53.08 74.02 11617 3.80 21.8 57.46 79.51
0612
L 2.0
11659 4.00 25.1 59.34 83.65 12825 4.20 27.4 63.90 89.05
0711
L 2.5
12674 4.20 18.7 63.60 88.73 13941 4.50 21.2 68.70 94.93
0712
L 2.5
13990 4.70 24.1 70.83 99.62 15389 5.10 27.8 76.73 107.12
0713
L 2.5
15307 5.30 31.3 78.43 111.37 16838 5.70 35.6 84.68 119.11
0812
L 2.5
16322 5.50 26.2 82.60 116.25 17954 6.00 30.7 89.55 125.19
0813
L 2.5
17858 6.20 34.0 91.46 129.94 19644 6.70 39.1 98.84 139.19
0913
L 2.5
20409 7.00 36.0 104.25 147.94 22450 7.50 40.8 112.48 158.01
0914
L 2.5
22165 7.80 45.6 114.32 163.46 24382 8.30 51.0 123.52 175.07
1014
L 2.0
24936 8.80 37.7 128.60 183.96 27430 9.40 42.4 139.06 197.28
1015
L 2.0
26911 9.50 45.2 139.48 200.33 29602 10.20 51.2 150.74 214.64
1115
L 2.0
29901 10.70 48.4 155.25 223.31 32891 11.50 55.0 167.81 239.34
1116
S 2.0
32095 11.00 30.7 162.58 230.16 35305 11.70 34.3 175.35 245.61
1216
S 2.5
35305 12.00 28.2 178.52 252.46 38836 13.00 32.6 193.16 270.89
1217
S 2.5
37719 13.00 33.7 192.04 273.01 41491 14.00 38.5 207.47 292.22
1317
S 2.5
41148 14.20 35.7 209.49 297.89 45263 15.00 39.4 225.56 317.01
1417
S 2.5
44577 15.50 38.3 227.19 323.34 49035 16.30 41.9 244.45 343.70
1518
H 2.0
49734 17.20 37.5 253.86 361.84 54707 18.50 42.7 274.48 387.86
1618
H 2.0
53287 18.80 40.1 272.84 389.75 58616 20.00 44.7 294.52 416.65
1719
H 2.0
60350 21.00 46.1 309.61 443.07 66385 22.50 52.2 334.53 474.44
1820
L 2.5
67853 22.00 19.5 333.31 462.84 74638 24.00 22.8 361.35 498.04
1822
L 2.5
75315 25.00 25.6 374.94 526.08 82847 27.00 29.5 405.73 564.40
1825
L 2.5
86507 30.00 37.9 438.78 624.21 95158 32.00 42.7 473.18 665.98
1826
L 2.5
90238 31.00 41.0 458.49 653.15 99262 33.50 47.2 496.06 700.82
Notes:
1) Entering Dry Bulb Temperature (EDB): 27°C
2) Entering Wet Bulb Temperature: 19.5°C
3) Entering Water Temperature: 7°C
4) Leaving Water Temperature: 12°C
