McQuay MDM Series User Manual

21
Filter Section
Good air quality is of utmost importance. A key ingredient in maintaining good air quality is air filtration. Our
standard configuration of the filter is flat panel pre-filter and the material is non-moving cloth with the
efficiency G3. The bag media filter and HEPA filter are optional.
WEIGHT (Kg) INICIAL RESISTANCE (Pa)
MODEL SPECIFICATION (QUANTITY)
FLAT PANEL BAG FLAT PANEL BAG
0306
15"x16"(1) 15"x20"(1) 0 0 74 126 65 55
0308
15"x16"(3) 0 0 0 84 144 65 55
0408
20"x16"(3) 0 0 0 86 148 65 55
0410
20"x20"(3) 0 0 0 96 166 65 55
0509
25"x20"(2) 25"x16"(1) 0 0 95 165 65 55
0510
25"x20"(3) 0 0 0 100 174 65 55
0511
25"x16"(3) 25"x20"(1) 0 0 103 179 65 55
0610
16"x20"(6) 0 0 0 104 182 65 55
0611
16"x16"(6) 16"x20"(2) 0 0 107 187 65 55
0612
16"x16"(2) 16"x20"(6) 0 0 112 196 65 55
0711
20"x16"(6) 20"x20"(2) 0 0 112 196 65 55
0712
20"x16"(2) 20"x20"(6) 0 0 117 205 65 55
0713
20"x20"(8) 0 0 0 123 215 65 55
0812
20"x16"(1) 20"x20"(3) 25"x16"(1) 25"x20"(3) 123 217 65 55
0813
20"x20"(4) 25"x20"(4) 0 0 127 223 65 55
0913
25"x20"(8) 0 0 0 139 247 65 55
0914
25"x20"(6) 25"x25"(2) 0 0 142 252 65 55
1014
20"x20"(9) 20"x25"(3) 0 0 150 268 65 55
1015
20"x20"(6) 20"x25"(6) 0 0 155 277 65 55
1115
20"x20"(4) 20"x25"(6) 25"x25"(2) 0 157 281 65 55
1116
20"x25"(8) 25"x25"(4) 0 0 160 286 65 55
1216
25"x25"(8) 20"x25"(4) 0 0 169 303 65 55
1217
25"x20"(9) 25"x25"(2) 20"x20"(4) 0 178 320 65 55
1317
25"x20"(12) 25"x25"(3) 0 0 182 328 65 55
1417
20"x20"(16) 20"x25"(4) 0 0 187 337 65 55
1518
20"x20"(6) 20"x25"(11) 25"x25"(3) 0 193 349 65 55
1618
25"x20"(9) 25"x25"(11) 0 0 198 358 65 55
1719
25"x20"(4) 25"x25"(16) 0 0 207 375 65 55
1820
20"x25"(15) 25"x25"(10) 0 0 218 396 65 55
1822
20"x20"(9) 20"x25"(15) 25"x25"(6) 0 226 408 65 55
1825
20"x20"(24) 25"x20"(16) 0 0 233 419 65 55
1826
20"x20"(6) 20"x25"(19) 25"x25"(10) 0 238 428 65 55
Notes:
1) The section weight includes the weight of filter and casing.
2) The specification of the flat panel filter and bag filter is the same except the thickness. The thickness of flat panel filter is 2
inches; the thickness of bag filter is 1 inch and the length of bag is 15 inches.
