22 Service Manual SM-MDS_(ii)
3.4.1 Wireless Handset G17
1. Transmission Source
2. Signal Transmission Indication
 Blink to confirm that the last setting has been transmitted to the unit.
3. Temperature Setting
 Temperature setting range is from 16°C to 30°C (optional setting 20°C to 30°C).
4. Personalize Setting
 Press and hold for 3s, then will blink. Press again to cycle between and ..
 Set the desire setting, then leave the handset for 4s without pressing any key and it will save the setting
into the program.
 Press once to activate the P1 setting, press again to cycle between P1 and P2.
 Press any key to deactivate the personalize setting.
5. Automatic Air Swing (optional)
 Press the SWING button to activate the automatic air swing function. Press again to stop the louver
at the desired direction.
6. Ionizer Function (For WM - G series only)
 Press button to activate the negative ion function, which will refresh the indoor air effectively.
7. Sleep Mode Setting
 This function is available under COOL, HEAT and AUTO mode.
 When under cooling mode, the set temperature is increased by 0.5°C after 30 minutes, 1°C after an
hour, and 2°C after 2 hours.
 When under heating mode, the set temperature is decreased by 1°C after 30 minutes, 2°C after an hour,
and 3°C after 2 hours.
8. Operating Mode
 Press the MODE button to select the type of operating mode.
 For cooling only unit, the available modes are: COOL, DRY and FAN.
9. Fan Speed Selection
 Press the button continuously will toggle the fan speed in the following order:
Low Med High Auto
 Stop pressing when the desired fan speed appears on the display screen.
3
