1.3 Basic Layout of MDS System
Generally, MDS system consists of outdoor unit, indoor unit, refnet or distributor and EXV box.
1.4 Maximum Connectable Indoor
MDS system is very flexible and versatile as one outdoor unit can be connected to multiple indoor units. The
table below shows the maximum connectable indoor units for each outdoor:
R22 Model
R410A Model
Maximum Indoor Quantity
MDS 030A(R)
-
5
MDS 040A(R)
-
6
MDS 050A(R)
5MDS 050B(R)
8
MDS 060A(R)
5MDS 060B(R)
9
MDS 070A(R)
5MDS 070B(R)
11
MDS 080B(R)
5MDS 080B(R)
13
MDS 100B(R)
5MDS 100B(R)
16
MDS 120B(R)
5MDS 120B(R)
16
-
5MDS 140B(R)
20
MDS 150B(R)
-
20
-
5MDS 160B(R)
20
MDS 180B(R)
5MDS 180B(R)
24
MDS 200B(R)
5MDS 200B(R)
24
MDS 220B(R)
5MDS 220B(R)
24
MDS 240B(R)
5MDS 240B(R)
24
MDS 260B(R)
5MDS 260B(R)
32
MDS 280B(R)
5MDS 280B(R)
32
MDS 300B(R)
5MDS 300B(R)
32
MDS 320B(R)
5MDS 320B(R)
32
-
5MDS 340B(R)
36
-
5MDS 360B(R)
36
-
5MDS 380B(R)
36
-
5MDS 400B(R)
38
-
5MDS 420B(R)
38
-
5MDS 440B(R)
38
-
5MDS 460B(R)
38
-
5MDS 480B(R)
38
-
5MDS 500B(R)
38
