IOMM Starter 23
DESCRIPTION Values DEFAULT
P6
Sequence Complete
Delay Time
0.1 to 5.0 seconds 2.0
P7 Overcurrent Trip Level OFF, 50 to 800 %RLA OFF
P8
Overcurrent Trip Delay
Time
0.1 to 90.0 seconds 2.0
P9 Rated RMS Voltage
100, 110, 120, 200, 208,
220, 230, 240, 350, 380,
400, 415, 440, 460, 480,
575, 600, 660, 1000 Volts
480
P10 Over Voltage Trip Level OFF, 1 to 40 % rated Volts 10
P11 Under Voltage Trip Level OFF, 1 to 40 % rated Volts 15
P12
Over/Under Voltage
Delay Time
0.1 to 90.0 seconds 1.0
P13
Current Imbalance Trip
Level
5 to 40 % 20
P14 Auto Fault Reset Time OFF, 1 to 120 seconds 60
P15 CT Ratio
72, 96, 144, 288, 864,
2640, 2880, 5760, 8000
2640
P16 Control Source
TEr: Terminal
NEt: Network
tEr
P17 Modbus Address 1 to 247 2
P18 Modbus Baud Rate 1.2, 2.4, 4.8, 9.6, 19.2 Kbps 19.2
P19 Modbus Timeout OFF, 1 to 120 seconds 3
P20 Analog Output Function 0 to 11 1
P21 Analog Output Span 1 to 125 % 100
P22 Analog Output Offset 0 to 99 % 0
P23 Passcode 0 to 9999 –
P24 Fault Log xFyy –
Fault/Alarm Codes (LVYD)
Description
Auto
Reset
00 No fault -
02 Motor Thermal Overload Trip N
10 Phase Rotation Error, not ABC Y
12 Low Line Frequency Y
13 High Line Frequency Y
15 Input power not three phase Y
21 Low Line L1-L2 Voltage Y
22 Low Line L2-L3 Voltage Y
23 Low Line L3-L1 Voltage Y
24 High Line L1-L2 Voltage Y
25 High Line L2-L3 Voltage Y
26 High Line L3-L1 Voltage Y
27 Phase Loss Y
28 No Line Voltage Y
30 I.O.C. (Instantaneous Overcurrent) N
31 Overcurrent N
37 Current Imbalance Y
38 Ground Fault N
39 No Current at Run Y
40 Open Line or Motor Lead N
41 Current While Stopped N
48 2M Feedback Fault (on DIN#2) N
50 Control Power Low Y
51 Current Sensor Offset Error N
