McQuay RVSS14 User Manual

IOMM Starter 33
Description
Values
Default
P8 Overcurrent Trip Delay Time 0.1 to 90.0 seconds 2.0
P9 Rated RMS Voltage
208, 220, 230, 240, 380, 415,
440, 460, 480, 575 Volts
480
P10 Over Voltage Trip Level OFF, 1 to 40 % rated Volts 10
P11 Under Voltage Trip Level OFF, 1 to 40 % rated Volts 15
P12 Over/Under Voltage Delay Time 0.1 to 90.0 seconds 1.0
P13 Current Imbalance Trip Level 5 to 40 % 20
P14 Auto Fault Reset Time OFF, 1 to 120 seconds 60
P15 CT Ratio
72, 96, 144, 288, 864, 2640,
2880, 5760, 8000
2640
P16 Control Source
TEr: = Terminal, NEt: =
Network
TEr
P17 Modbus Address 1 to 247 2
P18 Modbus Baud Rate 1.2, 2.4, 4.8, 9.6, 19.2 Kbps 19.2
P19 Modbus Timeout OFF, 1 to 120 seconds 3
P20 Analog Output Function 0 to 11 1
P21 Analog Output Span 1 to 125 % 100
P22 Analog Output Offset 0 to 99 % 0
P23 Passcode (See Note) 0 to 9999 Disabled
P24 Fault Log xFyy –
Table 10, Setpoints, Solid State Starter
Description Values Default
P1 Motor FLA 1 to 9999 Amps 10
P2 Motor RLA 1 to 9999 Amps 10
P3 Motor Service Factor 1.00 to 1.99 1.08
P4 Motor Overload Class OFF, 1 to 40 10
P5 Initial Motor Current 50 to 400 %FLA 100
P6 Maximum Motor Current 100 to 800 %FLA 600
P7 Ramp Time 0 to 300 seconds 15
P8 UTS Time (Up To Speed) 1 to 900 seconds 30
P9 Stop Mode
CoS: Coast
dcL: Voltage Decel
CoS
P10 Decel Begin Level 100 to 0 %Volts 40
P11 Decel End Level 50 to 0 %Volts 20
P12 Decel Time 1 to 180 seconds 15
P13 Default Meter Display 0 to 19 0
P14 Overcurrent Trip Level OFF, 50 to 800 %RLA OFF
P15 Overcurrent Trip Delay Time 0.1 to 90.0 seconds 2.0
P16 Rated RMS Voltage
208, 220, 230, 240, 380, 415, 440,
460, 480, 575 Volts
480
P17 Over Voltage Trip Level OFF, 1 to 40 % rated Volts 10
P18 Under Voltage Trip Level OFF, 1 to 40 % rated Volts 15
P19 Over/Under Voltage Delay Time 0.1 to 90.0 seconds 1.0
P20 Current Imbalance Trip Level 5 to 40 % 35
P21 Controlled Fault Stop OFF, On OFF
P22 Auto Fault Reset Time OFF, 1 to 120 seconds 60
P23 CT Ratio
72, 96, 144, 288, 864, 2640, 2880,
5760, 8000
2640
P24 Control Source
Ter: Terminal, Net:
Network
tEr
P25 Modbus Address 1 to 247 2
Continued on next page.
