54 IOMM Starter
Menu Structure
The Micro II control has a 2 level menu structure. There are eight main menus that contain
parameters related to the different functions of the starter and five of the main menus contain
additional sub-menus that divide the parameters into functional groups. The following shows
the structure of the menu structure.
Table 14, Main Menu
Quick Start
Motor
Nameplate
Starter Setup Motor Protection
Meters &
Relays
Starter Modes Overload Class Meters Setup
Forward1 Profile Line Current
Standard
Relays
Forward2 Profile Line Voltage
Extended
Relays
Tachometer Setup Line Frequency
Decel Setup Ground Fault
Port Ctl Setup Shorted Scr
True Torque Ramp Over Curr. Trip
Under Curr. Trip
Start Lockouts
Starting Timers
Permissive Input
Misc.
Fault Classes
Event Recorder Control Config Factory Setup RTD Setup
System Clock Hardware Setup Rtd Module Setup
System Password Bist Setup/Run Rtd Setpnts 1-8
Comm. Settings Factory Control RTD Setpnts 9-16
Options List
Software Part#
Changing a Parameter
To change a parameter, follow these steps:
• View the desired parameter by following the “Viewing a Parameter”
instructions.
• Press the Enter button to switch to the change parameter screen.
• Press the Up or Down buttons to get the desired value on the screen.
• Press the Enter button to store the new value.
Example
The ramp time is set to 30 seconds and it is to be changed to 20 seconds.
The following steps must be taken to change the ramp time.
• Press the Menu button to enter the menu system.
• Press the Down button twice to get to the Starter Setup screen.
• Press the Enter button to access the Starter Setup menu.
• Press the Down button once to display the Forward1 Profile.
• Press the Enter button to access the Forward1 Profile sub-menu.
• Press the Down button twice to display the Ramp Time parameter.
• Press the Enter button to allow a change to the ramp time.
• Press the Down button repeatedly to change the Ramp Time to the
desired value.
• Press the Enter button to store the value.
Continued
