36 Product Manual PM WSC/WDC
WSC 100-126, 600 to 1300 tons
VESSEL CODE OVERALL LENGTH CONNECTIONS
1&3
PASS
2
PASS
HEAD CONN
BOTH ENDS
OVERALL
HEIGHT
OVERALL
WIDTH W/O
STARTER
CENTER OF GRAVITY FOOTPRINT
EVAP COND
A A A B C X Y Z D E F G
EVAP
2
PASS
COND
2
PASS
3012 3012
175
(4445)
167
(4242)
175
(4445)
97
(2464)
61
(1549)
65
(1651)
47
(1194)
21
(553)
148
(3759)
145
(3683)
61
(1549)
53
(1346)
10 10
3612 3012
175
(4445)
168
(4267)
175
(4445)
99
(2515)
74
(1880)
68
(1727)
47
(1194)
27
(686)
148
(3759)
145
(3683)
74
(1880)
66
(1676)
12 10
3612 3612
175
(4445)
168
(4267)
175
(4445)
99
(2515)
80
(2032)
68
(1727)
46
(1168)
31
(787)
148
(3759)
145
(3683)
80
(2032)
72
(1829)
12 12
4212 3612
175
(4445)
170
(4318)
175
(4445)
99
(2515)
86
(2184)
69
(1753)
45
(1143)
35
(889)
148
(3759)
145
(3683)
86
(2184)
78
(1981)
14 12
4212 4212
175
(4445)
170
(4318)
175
(4445)
102
(2591)
92
(2337)
69
(1753)
45
(1143)
37
(940)
148
(3759)
145
(3683)
92
2337)
84
(2134)
14 14
4812 4212
181
(4597)
175
(4445)
181
(4597)
106
(2692)
98
(2489)
69
(1753)
46
(1168)
42
1067)
148
(3759)
145
(3683)
98
2489)
90
(2286)
18 14
4812 4812
181
(4597)
175
(4445)
181
(4597)
106
(2692)
104
(2642)
70
(1778)
46
(1168)
46
(1168)
145
(3683)
145
(3683)
104
(2642)
96
(2438)
18 18
Note: See notes on page 33.
