Product Manual PM WSC/WDC 37
WDC 048/050, 180 to 320 tons
VESSEL CODE OVERALL LENGTH OVERALL CONNECTIONS
1&3 2 HEAD CONN WIDTH W/O
EVAP COND PASS PASS BOTH ENDS
OVERALL
HEIGHT
STARTER
CENTER OF GRAVITY FOOTPRINT
A A A B C X Y Z D E F G
EVAP
2
PASS
COND
2
PASS
E1812 C1612
169
(4298)
170
(4134)
169
(4298)
74
(1883)
34
(876)
66
(1608)
34
(857)
14
(352)
150
(3802)
147
(3726
35
(876)
29
(724)
6 5
E1812 C1812
169
(4299)
163
(4132)
169
(4299)
76
(1934)
34
(876)
65
(165)
33
(875)
14
(362)
150
(3802)
147
(3726
35
(876)
29
(724)
6 6
E1816 C1816
218
(5544)
212
(5380)
218
(5544)
76
(1934)
34
(876)
97
(2458)
31
(781)
14
(368)
199
(5050)
196
(4974)
35
(876)
29
(724)
6 6
E2012 C1812
169
(4299)
163
(4147)
169
(4299)
78
(1984)
34
(876)
67
(1705)
34
(873)
14
(359)
150
(3802)
147
(3726
35
(876)
29
(724)
6 6
E2016 C1816
218
(5544)
212
(5393)
218
(5544)
78
(1994)
34
(876)
93
(2359)
32
(813)
14
(365)
199
(5050)
196
(4974)
35
(876)
29
(724)
6 6
E2212 C2212
169
(4299)
164
(4158)
169
(4299)
79
(2020)
40
(1024)
72
(1838)
29
(733)
15
(384)
150
(3802)
147
(3726
41
(1024)
35
(872)
8 8
E2216 C2216
218
(5544)
213
(5404)
218
(5544)
79
(2020)
40
(1024)
93
(2367)
31
(800)
20
(498)
199
(5050)
196
(4974)
41
(1024)
35
(872)
8 8
E2612 C2212
169
(4299)
165
(4180)
169
(4299)
85
(2149)
44
(1131)
75
(1918)
35
(902)
20
(505)
150
(3802)
147
(3726
45
(1131)
39
(979)
8 8
E2616 C2216
218
(5544)
214
(5428)
218
(5544)
85
(2149)
44
(1131)
97
(2467)
36
(921)
19
(492)
199
(5050)
196
(4974)
45
(1131)
39
(979)
8 8
Note: See notes on page 33.
