42 Product Manual PM WSC/WDC
WDC 126, 1600 to 2700 tons
VESSEL CODE OVERALL LENGTH OVERALL CONNECTIONS
1&3 2 HEAD CONN WIDTH W/O
EVAP COND PASS PASS BOTH ENDS
OVERALL
HEIGHT
STARTER
CENTER OF GRAVITY FOOTPRINT
A A A B C X Y Z D E F G
EVAP
2
PASS
COND
2
PASS
E3616 C3616
224
(5692)
218
(5528)
224
(5692)
104
(2652)
95
(2419)
93
(2353)
51
(1292)
40
(1003)
199
(5050)
196
(4974)
95
(2419)
87
(2216)
12 12
E4216 C4216
224
(5692)
219
(5554)
224
(5692)
107
(2722)
100
(2545)
94
(2381)
50
(1254)
44
(1105)
199
(5050)
196
(4974)
100
(2545)
92
(2342)
14 16
E4816 C4816
230
(5848)
224
(5703)
230
(5848)
116
(2956)
110
(2792)
95
(2400)
52
(1318)
51
(1292)
199
(5050)
196
(4974)
110
(2792)
102
(2589)
18 18
E4220 C4220
272
(6909)
267
(6772)
272
(6909)
102
(2591)
92
(2343)
117
(2991)
46
(1165)
36
(921)
247
(6269)
244
(6193)
92
(2343)
84
(2140)
14 16
E4224 C4224
320
(8128)
315
(7991)
320
(8128)
102
(2591)
92
(2343)
136
(3457)
44
(1121)
37
(946)
295
(7487)
292
(7412)
92
(2343)
84
(2140)
14 16
E4820 C4820
276
(7010)
271
(6890)
276
(7010)
111
(2810)
104
(2648)
118
(3007)
49
(1238)
43
(1105)
247
(6269)
244
(6193)
104
(2648)
96
(2444)
18 18
E4824 C4824
324
(8230)
319
(8109)
324
(8230)
111
(2810)
104
(2648)
138
(3496)
47
(1194)
45
(1133)
295
(7487)
292
(7412)
104
(2648)
96
(2444)
18 18
Note: See notes on page 33.
