McQuay WDC

Product Manual PM WSC/WDC 41
WDC 100, 1200 to 1700 tons
VESSEL CODE OVERALL LENGTH OVERALL CONNECTIONS
1&3 2 HEAD CONN WIDTH W/O
EVAP COND PASS PASS BOTH ENDS
OVERALL
HEIGHT
STARTER
CENTER OF GRAVITY
W/O STARTER
FOOTPRINT
A A A B C X Y Z D E F G
EVAP
2
PASS
COND
2
PASS
E3616 C3616
224
(5692)
218
(5528)
224
(5692)
104
(2652)
95
(2419)
93
(2353)
51
(1292)
40
(1003)
199
(5050)
196
(4974)
95
(2419)
87
(2216)
12 12
E4216 C4216
224
(5692)
219
(5554)
224
(5692)
107
(2722)
100
(2545)
94
(2381)
50
(1254)
44
(1105)
199
(5050)
196
(4974)
100
(2545)
92
(2342)
14 16
E4816 C4816
230
(5848)
224
(5703)
230
(5848)
116
(2956)
110
(2792)
95
(2400)
52
(1318)
51
(1292)
199
(5050)
196
(4974)
110
(2792)
102
(2589)
18 18
E4220 C4220
272
(6909)
267
(6772)
272
(6909)
102
(2591)
92
(2343)
117
(2991)
46
(1165)
36
(921)
247
(6269)
244
(6193)
92
(2343)
84
(2140)
14 16
E4820 C4820
276
(7010)
271
(6890)
276
(7010)
111
(2810)
104
(2648)
118
(3007)
49
(1238)
43
(1105)
247
(6269)
244
(6193)
104
(2648)
96
(2444)
18 18
Note: See notes on page 33.
