Mec 3072RT - Primary Machine Components Index

"3072RT / 3772RT / 3772RT HD" Service & Parts Manual - ANSI Specifications March 2008
Page VII
Component Service Section Parts Section
Platform Assembly
Upper Controls 2 | 4 | 5 1 | 2
Deck and Rails 32
Chain Closure2
Optional Gate 2
Rollout Deck 2
Control Terminal Strip 1
Horn (optional) 2 1
Lift Assembly
Beams intro3
Maintenance Lock intro3
Lift Cylinders 1 | 3 | 4 | 5 3 | 5
Limit Switch 2 | 4 3
Base Assembly
Front Drive Motors intro | 1 | 3 | 4 | 5 4 | 5 | 6
R Drive Motors w/Brakes intro | 1 | 3 | 4 | 5 4 | 5 | 6
Steering Components 1 | 3 3 | 5 | 6
Steering Components 1 | 3 | 4 | 5 3 | 5 | 6
Wheels & Tires intro | 3 6
Hubs intro6
Slide Block intro6
Emergency Lowering1
Hoses & Cables 1 | 2 | 3 | 5 | 6
Outrigger (Option) 1 | 3 | 4 | 5 5 | 6
LPG (Option)36
Power Module
Engine 3 | 4 | 5 6
Hydraulic Pump 1 | 3 | 4 | 5 6
Hydraulic reservoir intro | 1 6
Hydraulic Filter intro | 1 6
Component Service Section Parts Section
Control Module
Lower Controls 2 | 3 | 4 | 5 1 | 6
Hydraulic Manifold 1 | 3 | 4 | 5 5 | 6
Parking Brake Release1
Emergency Lowering1
Fuel Tank6
Fuel Shutoff 6
Power to Platform6
Tilt Sensor 2 | 3 | 4 | 5 6
Battery & Disconn ect 2 | 3 | 4 | 5 6
Outrigger Manifold 1 | 3 | 4 | 5 5 | 6
Outrigger Control Module
(Outrigger Option)2 | 5 6
AC Generator (Option) 5 5 | 6
Relays
Platform Power 2 | 4 | 5 1
Torque Speed 2 | 4 | 5 6
Throttle 2 | 4 | 5 6
Preheat 2 | 4 | 5 6
Outrigger (Option) 3 | 4 | 5 6
AC Generator (Option) 5 6
PRIMARY MACHINE COMPONENTS
